What is the warranty offered in Tata LP 407 CNG bus chassis ?

Tata LP 407 CNG bus comes with a standard warranty of

Tata LP 407 CNG BS6 bus specifications

Q: What is the engine capacity of Tata LP 407 CNG bus?

Tata LP 407 CNG bus chassis comes with 4 cylinder Tata 3.8 SGI# Naturally Aspiratedengine and the engine displacement is 3783 cc

Rate This Vehicle

From ₹ 18.01 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata LP 407 CNG Bus Chassis for this month

Tata LP 407 CNG - 6 Wheeler Bus Highlights

Power

GVW

7000 Kg

Fuel

CNG

Engine

3783 cc

Cylinders

Key Specifications of Tata LP 407 CNG Bus Chassis

Engine
Configuration

Tata LP 407 CNG Bus Chassis Engine
Engine
Tata 3.8 SGI
Naturally Aspirated
Tata LP 407 CNG Bus Chassis Fuel Injection System
Fuel Injection System
Sequential Gas Injection
Tata LP 407 CNG Bus Chassis Engine Displacement
Engine Displacement
3783 cc
Tata LP 407 CNG Bus Chassis Engine Cylinders
Engine Cylinders
4
Tata LP 407 CNG Bus Chassis Engine Location
Engine Location
Front
Tata LP 407 CNG Bus Chassis Power
Power
83 HP@2500 rpm
Tata LP 407 CNG Bus Chassis Torque
Torque
285 Nm@1200-1500 rpm
Tata LP 407 CNG Bus Chassis Clutch
Clutch
280 mm dia
Tata LP 407 CNG Bus Chassis Transmission
Transmission
5 speed (5F+1R)
Tata LP 407 CNG Bus Chassis Gearbox
Gearbox
GB 400
Cable Shift
Tata LP 407 CNG Bus Chassis Emission Norms Compliance
Emission Norms Compliance
BS6
Tata LP 407 CNG Bus Chassis Fuel Type
Fuel Type
CNG
Tata LP 407 CNG Bus Chassis Fuel Tank Capacity
Fuel Tank Capacity
360 Litres
Tata LP 407 CNG Bus Chassis Electricals Battery
Electricals Battery
12V-120 Ah, 120 Amp

Tata LP 407 CNG Bus Chassis GVW
GVW
7000 Kg
Tata LP 407 CNG Bus Chassis Overall Length
Overall Length
7190 mm
Tata LP 407 CNG Bus Chassis Vehicle Configuration
Vehicle Configuration
Chassis without face-cowl
Tata LP 407 CNG Bus Chassis Chassis Frame
Chassis Frame
Ladder type
Tata LP 407 CNG Bus Chassis Axle Configuration
Axle Configuration
4X2
Tata LP 407 CNG Bus Chassis Front Suspension
Front Suspension
Parabolic leaf springs
Tata LP 407 CNG Bus Chassis Rear Suspension
Rear Suspension
Parabolic leaf springs
Tata LP 407 CNG Bus Chassis Anti Roll Bar
Anti Roll Bar
Front and Rear
Tata LP 407 CNG Bus Chassis Tyres
Tyres
215/75 R17.5
Tubeless radial
6+1 Tyres
Tata LP 407 CNG Bus Chassis Wheelbase
Wheelbase
3600 mm
Tata LP 407 CNG Bus Chassis Turning Circle Diameter
Turning Circle Diameter
14.5 m
Tata LP 407 CNG Bus Chassis Ground Clearance
Ground Clearance
210 mm
Tata LP 407 CNG Bus Chassis Front Overhang
Front Overhang
1430 mm
Tata LP 407 CNG Bus Chassis Rear Overhang
Rear Overhang
2160 mm

Tata LP 407 CNG Bus Chassis Specification Highlights

Come here for details of engine performance and body configuration for the Tata LP 407 CNG bus Chassis. The driveline begins with a 4-cylinder Tata 3.8 SGI, Naturally Aspirated engine with a maximum power output of 83 HP and up to 285 Nm torque. The engine is coupled with a 5-speed, GB 400 Cable Shift gearbox. Parabolic leaf springs for improved passenger comfort are also offered to make your journeys more comfortable. The bus chassis has a ladder-type chassis frame. The bus is equipped with a tubeless radial tyre of 215/75 R17.5 and the wheelbase is 3600 mm. It is operated by CNG fuel and has a fuel tank capacity of 360 liters. The latest model of the Tata LP 407 CNG bus Chassis comes with an electrical battery of 12V-120 Ah, 120 Amp.
