Eicher 3009H : Skyline Pro School 52 Seater Bus Specifications

*Ex - showroom Price of Eicher 3009H : Skyline Pro School 52 Seater Bus is 27.76-32.86 Lakh*

From ₹ 27.76-32.86 Lakh*
*Ex-showroom Price


Don't miss out on the best discount offers on Eicher 3009H : Skyline Pro School 52 Seater Bus for this month

Eicher 3009H : Skyline Pro School 52 Seater - 6 Wheeler Bus Highlights

Power

Eicher 3009H : Skyline Pro School 52 Seater Bus Power

160
GVW

Eicher 3009H : Skyline Pro School 52 Seater Bus GVW

9800 Kg
Fuel

Eicher 3009H : Skyline Pro School 52 Seater Bus Fuel

Diesel
Engine

Eicher 3009H : Skyline Pro School 52 Seater Bus Engine

3760 cc
Cylinders

Eicher 3009H : Skyline Pro School 52 Seater Bus Cylinders

4

Key Specifications of Eicher 3009H : Skyline Pro School 52 Seater Bus

  • Engine
    E494
  • Fuel Injection System
    Common rail
  • Engine Displacement
    3760 cc
  • Engine Cylinders
    4
  • Engine Location
    Front
  • Power
    160 HP@2600 rpm
  • Torque
    500 Nm@1200-1800 rpm
  • Clutch
    330 mm dia
  • Transmission
    6 speed manual (6F+1R)
  • Gearbox
    ET40S6 Synchromesh
  • Emission Norms Compliance
    BS6
  • Fuel Type
    Diesel
  • Fuel Tank Capacity
    100 Litres
  • Electricals Battery
    Non AC: 12V, 130Ah
    AC: 12V, 130Ah x 2
  • GVW
    9800 Kg
  • Seating Layout
    3x2
  • Seating Capacity
    52+D
  • Passenger Door Type
    One jack-knife type
  • Floor Type
    Anti-skid vinyl flooring
  • Chassis Frame
    Domex frame
  • Axle Configuration
    4x2
  • Front Suspension
    Parabolic leaf springs
  • Rear Suspension
    Parabolic leaf springs
  • Anti Roll Bar
    Front only
  • Tyres
    235/75 R17.5
    6+1 tyres
  • Wheelbase
    4320 mm
  • Ground Clearance
    165 mm
  • Floor Height
    900 mm
  • Overall Length
    8957 mm
  • Overall Width
    2350 mm
  • Overall Height
    2893 mm (Non AC)
    3145 mm (AC)
  • Front Overhang
    2045 mm
  • Rear Overhang
    3134 mm

Eicher 3009H : Skyline Pro School 52 Seater Bus Specification Highlights

Check all the Eicher 3009H : Skyline Pro School 52 Seater bus specifications here on TrucksBuses Gearbox matched with this engine is 6 speed manual (6F+1R) Eicher 3009H : Skyline Pro School 52 Seater comes with a gross weight capacity of 9800 kg and length of 8957 mm For the comfortable journeys, parabolic leaf springs in front and parabolic leaf springs in rear does the duty in this Eicher bus Other Eicher 3009H : Skyline Pro School 52 Seater bus specifications like chassis, tyre, body width, turning circle dia, engine cc are available here in the tables on this page.

Frequently Asked Questions on Eicher 3009H : Skyline Pro School 52 Seater Bus

Eicher 3009H : Skyline Pro School 52 Seater bus price starts from Rs 27.76-32.86 Lakh*. The 2024 price of Eicher 3009H : Skyline Pro School 52 Seater bus can vary slightly from state to state and city to city.

Eicher 3009H : Skyline Pro School 52 Seater bus GVW is 9800 Kg

Eicher 3009H : Skyline Pro School 52 Seater bus can be purchased in multiple seating options depending on requirement. The seating capacity of Eicher 3009H : Skyline Pro School 52 Seater bus is 52+D seats

Eicher 3009H : Skyline Pro School 52 Seater bus comes with 4 cylinder E494 engine and the engine displacement is 3760 cc

In terms of performance, Eicher 3009H : Skyline Pro School 52 Seater bus produces a maximum power of 160 HP@2600 rpm and a maximum torque of 500 Nm@1200-1800 rpm

Eicher 3009H : Skyline Pro School 52 Seater bus comes with a 6 speed manual (6F+1R) transmission

Eicher 3009H : Skyline Pro School 52 Seater bus comes with Air brakes

The tyre size of Eicher 3009H : Skyline Pro School 52 Seater bus is 235/75 R17.5# 6+1 tyres

Eicher 3009H : Skyline Pro School 52 Seater bus comes with Diesel fuel option and its fuel tank capacity is 100 Litres

The monthly EMI of any bus depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Eicher 3009H : Skyline Pro School 52 Seater bus is expected to be around Rs 58982 for a 5 year period
