What is Isuzu D-Max gradeability ?

Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Isuzu D-Max is .

Isuzu D-Max specifications | TrucksBuses.com

Rate This Vehicle

From ₹ 10.55 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Isuzu D-Max Pickup for this month

Download Isuzu D-Max Pickup Brochure

Check out the Isuzu D-Max Pickup PDF brochure at TrucksBuses.com with all features and specifications.

Isuzu D-Max - 4 Wheeler Highlights

Power

GVW

2990 Kg

Fuel

Diesel

Engine

2499 cc

Cylinders

Isuzu D-Max Pickup Engine
Engine
Common Rail, VGS Turbo Intercooled
Isuzu D-Max Pickup Engine Displacement
Engine Displacement
2499 cc
Isuzu D-Max Pickup Engine Cylinders
Engine Cylinders
4
Isuzu D-Max Pickup Power
Power
78 HP@3800 rpm
Isuzu D-Max Pickup Torque
Torque
176 Nm@1500-2400 rpm
Isuzu D-Max Pickup Clutch
Clutch
Single plate dry
Isuzu D-Max Pickup Transmission
Transmission
5 speed (5F+1R)
Isuzu D-Max Pickup Gearbox
Gearbox
Manual
Isuzu D-Max Pickup Max Speed
Max Speed
80 Kmph
Isuzu D-Max Pickup Emission Norms Compliance
Emission Norms Compliance
BS6
Isuzu D-Max Pickup Fuel Type
Fuel Type
Diesel
Isuzu D-Max Pickup Fuel Tank Capacity
Fuel Tank Capacity
55 Litres

Isuzu D-Max Pickup GVW
GVW
2990 Kg
Isuzu D-Max Pickup Payload
Payload
1240 Kg
Isuzu D-Max Pickup Vehicle Configuration
Vehicle Configuration
Cabin and Chassis
Cabin with Flat bed body
Isuzu D-Max Pickup Seating Capacity
Seating Capacity
D+1
Isuzu D-Max Pickup Axle Configuration
Axle Configuration
4x2
Isuzu D-Max Pickup Front Suspension
Front Suspension
Independent, Double wishbone
Coil spring
Isuzu D-Max Pickup Rear Suspension
Rear Suspension
Semi elliptical leaf spring
Isuzu D-Max Pickup Tyres
Tyres
205 R16 - 6 PR Radial
Tubeless tyres
Isuzu D-Max Pickup Wheelbase
Wheelbase
3095 mm
Isuzu D-Max Pickup Turning Circle Diameter
Turning Circle Diameter
12.6 m
Isuzu D-Max Pickup Ground Clearance
Ground Clearance
220 mm
Isuzu D-Max Pickup Overall Length
Overall Length
5375 mm
Isuzu D-Max Pickup Overall Width
Overall Width
1860 mm
Isuzu D-Max Pickup Overall Height
Overall Height
1800 mm
Isuzu D-Max Pickup Front Track
Front Track
1570 mm
Isuzu D-Max Pickup Load Body Dimensions
Load Body Dimensions
8 ft x 5.7 ft

Isuzu D-Max Pickup Specification Highlights

The specification tab gives an opportunity you to find the specifications of the new Isuzu D-max 4 wheeler pickup. Latest Isuzu D-max comes with a common Rail, VGS Turbo Intercooled engine with 2499 cc displacement matched with a 5-speed manual gearbox transmission. The latest D-Max pickup runs on diesel fuel and gives superior mileage and a large fuel tank capacity of 55 litres. The Isuzu pickup comes in two vehicle configurations cabin and chassis and cabin with flat bed body. Isuzu D-max offers 205 R16 - 6 PR radial tubeless tyres which offers a ground clearance of 220 mm. If you want to know more about specifications like axle configuration, front suspension, rear suspension, overall length, maximum speed and load body dimensions you can check the table above.
