Ashok Leyland 4225 Truck GVW
GVW 42000 Kg
Ashok Leyland 4225 Truck Vehicle Configuration
Vehicle Configuration Cabin and chassis
Cabin with load body
Ashok Leyland 4225 Truck Load Body Options
Load Body Options Fixed Side Deck
High Side Deck
Ashok Leyland 4225 Truck Loading Span
Loading Span 28 ft
30 ft
32 ft
Ashok Leyland 4225 Truck Cabin Type
Cabin Type Sleeper cabin
Ashok Leyland 4225 Truck Cabin Tilt mechanism
Cabin Tilt mechanism Hydraulically tiltable
Ashok Leyland 4225 Truck Chassis Frame
Chassis Frame HSS material, bolted construction
Ashok Leyland 4225 Truck Axle Configuration
Axle Configuration 10x2
Ashok Leyland 4225 Truck Front Axle
Front Axle Forged I Beam, Reverse Elliot Type
Unitized wheel bearings (Optional)
Ashok Leyland 4225 Truck Rear Axle
Rear Axle Fully floating, Single speed
Unitized wheel bearings (Optional)
Ashok Leyland 4225 Truck Front Suspension
Front Suspension Semi elliptical leaf springs
Parabolic leaf spring (Optional)
Ashok Leyland 4225 Truck Rear Suspension
Rear Suspension Semi elliptical leaf springs
Parabolic helper spring
Slipper suspension (Optional)
Ashok Leyland 4225 Truck Anti Roll Bar
Anti Roll Bar Optional in front
Ashok Leyland 4225 Truck Tyres
Tyres 295/90R20 (Tube)
14+1 tyres
Ashok Leyland 4225 Truck Wheelbase
Wheelbase 6600 mm
Ashok Leyland 4225 Truck Turning Circle Diameter
Turning Circle Diameter 23.7 m
Ashok Leyland 4225 Truck Ground Clearance
Ground Clearance 253 mm
Ashok Leyland 4225 Truck Overall Length
Overall Length 10960 mm (28 ft)
11560 mm (30 ft)
11960 mm (32 ft)
Ashok Leyland 4225 Truck Overall Width
Overall Width 2570 mm
Ashok Leyland 4225 Truck Overall Height
Overall Height 3110 mm
Ashok Leyland 4225 Truck Front Overhang
Front Overhang 1550 mm
Ashok Leyland 4225 Truck Front Track
Front Track 2084 mm
Ashok Leyland 4225 Truck Rear Track
Rear Track 1876 mm
Ashok Leyland 4225 Truck Chassis Depth
Chassis Depth 275 mm
Ashok Leyland 4225 Truck Chassis Flange width
Chassis Flange width 75 mm
Ashok Leyland 4225 Truck Chassis Thickness
Chassis Thickness 8 / 8+6 mm
