Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck GVW
GVW 14250 Kg
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Vehicle Configuration
Vehicle Configuration Cabin and chassis
Cabin with load body
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Load Body Options
Load Body Options Fixed Side Deck
Drop Side Deck
High Side Deck
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Loading Span
Loading Span 17 ft
20 ft
22 ft
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Cabin Type
Cabin Type Sleeper cabin
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Cabin Tilt mechanism
Cabin Tilt mechanism Manually tiltable
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Chassis Frame
Chassis Frame Bolted ladder type
BSK 46
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Axle Configuration
Axle Configuration 4x2
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Front Axle
Front Axle Forged I Beam, Reverse Elliot Type
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Rear Axle
Rear Axle Fully floating single speed
Hypoid axle
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Front Suspension
Front Suspension Semi elliptical leaf springs
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Rear Suspension
Rear Suspension Semi elliptical leaf springs
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Tyres
Tyres 8.25R20 - 16 PR
6+1 tyres
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Wheelbase
Wheelbase 4200 mm
4750 mm
5200 mm
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Turning Circle Diameter
Turning Circle Diameter 17 m (17 ft body)
18.5 m (20 ft)
19.1 m (22 ft)
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Ground Clearance
Ground Clearance 232 mm
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Overall Length
Overall Length 7663 mm (17 ft body)
8558 mm (20 ft)
9283 mm (22 ft)
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Overall Width
Overall Width 2390 mm (body)
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Overall Height
Overall Height 3230 mm
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Front Track
Front Track 1964 mm
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Rear Track
Rear Track 1816 mm
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Chassis Depth
Chassis Depth 204 mm
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Chassis Flange width
Chassis Flange width 76 mm
Ashok Leyland Ecomet 1415 CNG Star Sleeper Truck Chassis Thickness
Chassis Thickness 6 mm
