BharatBenz 1015R Truck GVW
GVW 10600 Kg
BharatBenz 1015R Truck Payload
Payload 6.2 Tons* (20 ft HSD)
BharatBenz 1015R Truck Vehicle Configuration
Vehicle Configuration Cabin and chassis
Cabin with load body
BharatBenz 1015R Truck Load Body Options
Load Body Options Fixed Side Deck
Drop Side Deck
High Side Deck
BharatBenz 1015R Truck Loading Span
Loading Span 14.6 ft
17 ft
20 ft
21 ft
BharatBenz 1015R Truck Cabin Type
Cabin Type Day cab
BharatBenz 1015R Truck Cabin Tilt mechanism
Cabin Tilt mechanism Manually tiltable
BharatBenz 1015R Truck Chassis Frame
Chassis Frame Ladder type channel with cross members
BharatBenz 1015R Truck Axle Configuration
Axle Configuration 4x2
BharatBenz 1015R Truck Front Axle
Front Axle IF 3.6, Reverse Elliot Type
BharatBenz 1015R Truck Rear Axle
Rear Axle DANA S 130
BharatBenz 1015R Truck Front Suspension
Front Suspension Semi elliptical leaf springs
BharatBenz 1015R Truck Rear Suspension
Rear Suspension Semi elliptical leaf springs
BharatBenz 1015R Truck Anti Roll Bar
Anti Roll Bar Front and Rear (Optional)
BharatBenz 1015R Truck Tyres
Tyres 8.25x16 Nylon
235/75 R17.5 Tubeless (Optional)
6+1 tyres
BharatBenz 1015R Truck Wheelbase
Wheelbase 3360 mm
3760 mm
4250 mm
4800 mm
BharatBenz 1015R Truck Turning Circle Diameter
Turning Circle Diameter 13.4 m (3360 wb)
13.8 m (3760 wb)
15.7 m (4250 wb)
17.6 m (4800 wb)
BharatBenz 1015R Truck Ground Clearance
Ground Clearance 205 mm
BharatBenz 1015R Truck Overall Length
Overall Length 6380 mm (3360 wb)
6985 mm (3760 wb)
7950 mm (4250 wb)
8195 mm (4800 wb)
BharatBenz 1015R Truck Overall Width
Overall Width 2135 mm
BharatBenz 1015R Truck Overall Height
Overall Height 2420 mm
BharatBenz 1015R Truck Front Overhang
Front Overhang 1275 mm
BharatBenz 1015R Truck Rear Overhang
Rear Overhang 1745 mm (3360 wb)
1950 mm (3760 wb)
2425 mm (4250 wb)
2120 mm (4800 wb)
BharatBenz 1015R Truck Chassis Depth
Chassis Depth 228 mm
BharatBenz 1015R Truck Chassis Flange width
Chassis Flange width 80 mm
BharatBenz 1015R Truck Chassis Thickness
Chassis Thickness 6 mm
