BharatBenz 1917R Truck GVW
GVW 18500 Kg
BharatBenz 1917R Truck Payload
Payload 12 Tons*
BharatBenz 1917R Truck Vehicle Configuration
Vehicle Configuration Cabin and chassis
Cabin with load body
BharatBenz 1917R Truck Load Body Options
Load Body Options Fixed Side Deck
High Side Deck
BharatBenz 1917R Truck Loading Span
Loading Span 20 ft
22 ft
24 ft
31 ft
BharatBenz 1917R Truck Cabin Type
Cabin Type Sleeper cabin
BharatBenz 1917R Truck Cabin Tilt mechanism
Cabin Tilt mechanism Hydraulically tiltable
BharatBenz 1917R Truck Chassis Frame
Chassis Frame Ladder type channel with cross members
BharatBenz 1917R Truck Axle Configuration
Axle Configuration 4x2
BharatBenz 1917R Truck Front Axle
Front Axle IF 7.0 Reverse Elliot Type
BharatBenz 1917R Truck Rear Axle
Rear Axle MS145
RAR 5.57 / 6.17
BharatBenz 1917R Truck Front Suspension
Front Suspension Semi elliptical leaf springs
BharatBenz 1917R Truck Rear Suspension
Rear Suspension Semi elliptical leaf springs
BharatBenz 1917R Truck Anti Roll Bar
Anti Roll Bar Front and Rear (Optional)
BharatBenz 1917R Truck Tyres
Tyres 295/80 R22.5 Tubeless
295/90R20 (Optional)
6+1 tyres
BharatBenz 1917R Truck Wheelbase
Wheelbase 5100 mm
5900 mm
6700 mm
BharatBenz 1917R Truck Turning Circle Diameter
Turning Circle Diameter 17.3 m (5100 wb)
19.3 m (5900 wb)
22.6 m (6700 wb)
BharatBenz 1917R Truck Ground Clearance
Ground Clearance 275 / 273 mm
BharatBenz 1917R Truck Overall Length
Overall Length 8600 m m (20 ft body)
9400 mm (22 ft body)
9815 mm (24 ft body)
11995 mm (31 ft body)
BharatBenz 1917R Truck Overall Width
Overall Width 2335 mm
BharatBenz 1917R Truck Overall Height
Overall Height 2590 mm
BharatBenz 1917R Truck Front Overhang
Front Overhang 1335 mm
BharatBenz 1917R Truck Rear Overhang
Rear Overhang 2165 mm (5100 wb)
2580 mm (5900 wb)
3960 mm (6700 wb)
BharatBenz 1917R Truck Chassis Depth
Chassis Depth 272 mm
BharatBenz 1917R Truck Chassis Flange width
Chassis Flange width 70 mm
BharatBenz 1917R Truck Chassis Thickness
Chassis Thickness 6 mm
