Tata 1616 LPT Sleeper Truck GVW
GVW 16020 Kg
Tata 1616 LPT Sleeper Truck Payload
Payload 11 tons*
Tata 1616 LPT Sleeper Truck Vehicle Configuration
Vehicle Configuration Cabin chassis with PTO
Cabin with load body
Tata 1616 LPT Sleeper Truck Load Body Options
Load Body Options Fixed Side Deck
High Side Deck
Tata 1616 LPT Sleeper Truck Loading Span
Loading Span 17 ft
19 ft
20 ft
22 ft
24 ft
Tata 1616 LPT Sleeper Truck Cabin Type
Cabin Type Sleeper cabin
Tata 1616 LPT Sleeper Truck Chassis Frame
Chassis Frame Ladder type with cross members
Tata 1616 LPT Sleeper Truck Axle Configuration
Axle Configuration 4x2
Tata 1616 LPT Sleeper Truck Front Axle
Front Axle Forged I Beam, Reverse Elliot Type
Tata 1616 LPT Sleeper Truck Rear Axle
Rear Axle Fully Floating
Tata 1616 LPT Sleeper Truck Front Suspension
Front Suspension Parabolic leaf springs
With telescopic shock absorbers
Tata 1616 LPT Sleeper Truck Rear Suspension
Rear Suspension Semi elliptical leaf springs
Tata 1616 LPT Sleeper Truck Anti Roll Bar
Anti Roll Bar Yes
Tata 1616 LPT Sleeper Truck Tyres
Tyres 9R20- 16 PR
Radial tyres
6+1 tyres
Tata 1616 LPT Sleeper Truck Wheelbase
Wheelbase 3600 mm
4200 mm
4800 mm
Tata 1616 LPT Sleeper Truck Turning Circle Diameter
Turning Circle Diameter 16.6 m (4200 wb)
19.2 m (4800 wb)
Tata 1616 LPT Sleeper Truck Ground Clearance
Ground Clearance 225 mm
Tata 1616 LPT Sleeper Truck Overall Length
Overall Length 7995 mm (4200 wb)
8705 mm (4800 wb)
Tata 1616 LPT Sleeper Truck Overall Height
Overall Height 3200 mm
Tata 1616 LPT Sleeper Truck Load Body Width
Load Body Width 2425 mm
Tata 1616 LPT Sleeper Truck Front Track
Front Track 1950 mm
Tata 1616 LPT Sleeper Truck Rear Track
Rear Track 1809 mm
Tata 1616 LPT Sleeper Truck Chassis Thickness
Chassis Thickness 7 mm
