Tata 510 LPT Truck Specifications

*Ex - showroom Price of Tata 510 LPT Truck is 14.27-16.80 Lakh*

From ₹ 14.27-16.80 Lakh*
*Ex-showroom Price


Don't miss out on the best discount offers on Tata 510 LPT Truck for this month

Tata 510 LPT - 4 Wheeler Truck Highlights

Power

Tata 510 LPT Truck Power

100
GVW

Tata 510 LPT Truck GVW

5490 Kg
Fuel

Tata 510 LPT Truck Fuel

Diesel
Engine

Tata 510 LPT Truck Engine

2956 cc
Cylinders

Tata 510 LPT Truck Cylinders

4

Key Specifications of Tata 510 LPT Truck

  • Engine
    4SPCR
  • Fuel Injection System
    Common Rail
  • Engine Displacement
    2956 cc
  • Engine Cylinders
    4
  • Power
    100 HP@2800 rpm
  • Torque
    300 Nm@1200-2200 rpm
  • Clutch
    280 mm dia
    With clutch booster
  • Transmission
    5 speed (5F+1R)
  • Gearbox
    G400, Synchromesh
  • Max Speed
    80 Kmph
  • Emission Norms Compliance
    BS6
  • Fuel Type
    Diesel
  • Fuel Tank Capacity
    Diesel: 60 Litres
    Ad Blue: 18 Litres
  • Electricals Battery
    12V, 100 Ah
    Alternator: 75 Amps
  • GVW
    5490 Kg
  • Vehicle Configuration
    Cabin chassis with PTO
    Cabin with load body
  • Load Body Options
    Fixed Side Deck
    High Side Deck
  • Loading Span
    10.07 ft
  • Cabin Type
    Day cab
  • Cabin Tilt mechanism
    Manually tiltable
  • Chassis Frame
    Ladder type with cross members
  • Axle Configuration
    4x2
  • Front Axle
    Forged I Beam, Reverse Elliot Type
  • Rear Axle
    Banjo type
  • Front Suspension
    Semi elliptical leaf springs
    With telescopic shock absorbers
  • Rear Suspension
    Semi elliptical leaf springs
  • Tyres
    4+1 tyres

Tata 510 LPT Truck Specification Highlights

Check all the Tata 510 LPT specifications on TrucksBuses in the table above The main driveline of this Tata truck includes a 2956 cc 4 cylinder engine that produces a maximum power of 100 HP and a torque of 300 Nm It gets mated to 5 speed (5F+1R), G400, Synchromesh gearbox A gross weight of 5490 kg and multiple configurations allows the owner to carry multiple kinds of goods as per requirement There are multiple features in this Tata truck for enhancing driver comfort Other Tata 510 LPT truck specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the tables above.

Frequently Asked Questions on Tata 510 LPT Truck

GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Tata 510 LPT GVW is 5490 Kg

Tata 510 LPT comes with 4 cylinder 4SPCR engine and the engine displacement is 2956 cc

In terms of performance, Tata 510 LPT produces a maximum power of 100 HP@2800 rpm and a maximum torque of 300 Nm@1200-2200 rpm

Tata 510 LPT comes with a 5 speed (5F+1R) transmission along with a 280 mm dia# With clutch booster clutch

Tata 510 LPT comes with Diesel fuel option and its fuel tank capacity is Diesel: 60 Litres# Ad Blue: 18 Litres

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Tata 510 LPT is expected to be around Rs Not Available for a 5 year period

Tata 510 LPT comes with Hydraulic brakes# With auto slack adjuster# With booster

Tata 510 LPT truck comes with a standard warranty of 3 Years / 3 Lakh Km on driveline
