Tata Ultra T.19 truck specifications

Name: Tata Ultra T.19
Brand: Tata
SKU: TBN-20-8C387E

Rate This Vehicle

From ₹ 28.1-30.60 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata Ultra T.19 Truck for this month

Tata Ultra T.19 - 6 Tyre Truck Highlights

Power

210

GVW

18500 Kg

Fuel

Diesel

Engine

5005 cc

Cylinders

Key Specifications of Tata Ultra T.19 Truck

Engine
Configuration

Tata Ultra T.19 Truck Engine
Engine
5L Turbotronn 2.0
Tata Ultra T.19 Truck Fuel Injection System
Fuel Injection System
Common Rail
Tata Ultra T.19 Truck Engine Displacement
Engine Displacement
5005 cc
Tata Ultra T.19 Truck Engine Cylinders
Engine Cylinders
4
Tata Ultra T.19 Truck Power
Power
210 HP
Tata Ultra T.19 Truck Torque
Torque
700 Nm
Tata Ultra T.19 Truck Clutch
Clutch
380 mm dia
Hydraulic actuated
Tata Ultra T.19 Truck Transmission
Transmission
6 speed (6F+1R)
Tata Ultra T.19 Truck Gearbox
Gearbox
G750 DD
Tata Ultra T.19 Truck Max Speed
Max Speed
80 Kmph
Tata Ultra T.19 Truck Emission Norms Compliance
Emission Norms Compliance
BS6 OBD2
Tata Ultra T.19 Truck Fuel Type
Fuel Type
Diesel
Tata Ultra T.19 Truck Fuel Tank Capacity
Fuel Tank Capacity
245 Litres
Tata Ultra T.19 Truck Electricals Battery
Electricals Battery
2x12V,100 Ah

Tata Ultra T.19 Truck GVW
GVW
18500 Kg
Tata Ultra T.19 Truck Payload
Payload
11-12 Tons*
Tata Ultra T.19 Truck Vehicle Configuration
Vehicle Configuration
Cabin and chassis
Cabin with load body
Tata Ultra T.19 Truck Load Body Options
Load Body Options
High Side Deck
Tata Ultra T.19 Truck Loading Span
Loading Span
18 ft
20 ft
24 ft
32 ft
Tata Ultra T.19 Truck Cabin Type
Cabin Type
Sleeper cabin
Tata Ultra T.19 Truck Cabin Tilt mechanism
Cabin Tilt mechanism
Hydraulically tiltable
Tata Ultra T.19 Truck Chassis Frame
Chassis Frame
Ladder type with cross members
Tata Ultra T.19 Truck Axle Configuration
Axle Configuration
4x2
Tata Ultra T.19 Truck Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata Ultra T.19 Truck Rear Axle
Rear Axle
Single reduction
Tata Ultra T.19 Truck Front Suspension
Front Suspension
Parabolic leaf springs
Tata Ultra T.19 Truck Rear Suspension
Rear Suspension
Semi elliptical leaf springs
Tata Ultra T.19 Truck Tyres
Tyres
295/90R20 (Tube)
6+1 tyres
Tata Ultra T.19 Truck Wheelbase
Wheelbase
4920 mm
5300 mm
5560 mm
6800 mm
Tata Ultra T.19 Truck Ground Clearance
Ground Clearance
290 mm

Tata Ultra T.19 Truck Specification Highlights

Take a look at some of the latest specifications of the Tata Ultra T.19 truck. The Tata Ultra 6-wheeler truck comes with a 5-litre turbotron 2.0 engine, an engine displacement of 5005 cc, producing 210 horsepower with a torque of 700 Nm. The Tata Ultra T.19 GVM is 18.5 tonnes. The Tata Ultra T.19 payload capacity is 11 tonnes to 12 tonnes. The Ultra T.19 has a 6-speed gearbox transmission and a maximum speed of 80 kilometres per hour. The Tata 6-wheeler Ultra truck has a fuel capacity of 245 litres. You can also check the other specs such as cabin type, axle configuration and loading span in the table above.
