Tata T.7 Ultra Twin Tyre BS6 truck specifications

Name: Tata T.7 Ultra Twin Tyre
Brand: Tata
SKU: P-N-OnT2Tc

Rate This Vehicle

From ₹ 16.86-18.47 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata T.7 Ultra Twin Tyre Truck for this month

Download Tata T.7 Ultra Twin Tyre Truck Brochure

Check out the Tata T.7 Ultra Twin Tyre Truck PDF brochure at TrucksBuses.com with all features and specifications.

Tata T.7 Ultra Twin Tyre - 6 Wheeler Truck Highlights

Power

100

GVW

7490 Kg

Fuel

Diesel

Engine

2956 cc

Cylinders

Key Specifications of Tata T.7 Ultra Twin Tyre Truck

Engine
Configuration

Tata T.7 Ultra Twin Tyre Truck Engine
Engine
4SPCR
Tata T.7 Ultra Twin Tyre Truck Fuel Injection System
Fuel Injection System
Delphi
Tata T.7 Ultra Twin Tyre Truck Engine Displacement
Engine Displacement
2956 cc
Tata T.7 Ultra Twin Tyre Truck Engine Cylinders
Engine Cylinders
4
Tata T.7 Ultra Twin Tyre Truck Power
Power
100 HP@2800 rpm
Tata T.7 Ultra Twin Tyre Truck Torque
Torque
300 Nm@1200-2200 rpm
Tata T.7 Ultra Twin Tyre Truck Clutch
Clutch
280 mm dia
With clutch booster
Tata T.7 Ultra Twin Tyre Truck Transmission
Transmission
5 speed (5F+1R)
With cable shift
Tata T.7 Ultra Twin Tyre Truck Gearbox
Gearbox
G400, Synchromesh
Tata T.7 Ultra Twin Tyre Truck Gradeability
Gradeability
33%
Tata T.7 Ultra Twin Tyre Truck Max Speed
Max Speed
80 Kmph
Tata T.7 Ultra Twin Tyre Truck Emission Norms Compliance
Emission Norms Compliance
BS6
Tata T.7 Ultra Twin Tyre Truck Fuel Type
Fuel Type
Diesel
Tata T.7 Ultra Twin Tyre Truck Fuel Tank Capacity
Fuel Tank Capacity
Diesel: 60 Litres
Ad Blue: 18 Litres
Tata T.7 Ultra Twin Tyre Truck Electricals Battery
Electricals Battery
12V, 100 Ah
Alternator: 120 Amps

Tata T.7 Ultra Twin Tyre Truck GVW
GVW
7490 Kg
Tata T.7 Ultra Twin Tyre Truck Payload
Payload
4.3 tons
Tata T.7 Ultra Twin Tyre Truck Vehicle Configuration
Vehicle Configuration
Cabin chassis with PTO
Cabin with load body
Tata T.7 Ultra Twin Tyre Truck Load Body Options
Load Body Options
Fixed Side Deck
High Side Deck
Tata T.7 Ultra Twin Tyre Truck Loading Span
Loading Span
14 ft
17 ft
Tata T.7 Ultra Twin Tyre Truck Cabin Type
Cabin Type
Day cab
Tata T.7 Ultra Twin Tyre Truck Cabin Tilt mechanism
Cabin Tilt mechanism
Manually tiltable
Tata T.7 Ultra Twin Tyre Truck Chassis Frame
Chassis Frame
Ladder type with cross members
Tata T.7 Ultra Twin Tyre Truck Axle Configuration
Axle Configuration
4x2
Tata T.7 Ultra Twin Tyre Truck Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata T.7 Ultra Twin Tyre Truck Rear Axle
Rear Axle
Banjo type
Tata T.7 Ultra Twin Tyre Truck Front Suspension
Front Suspension
Parabolic leaf springs
With telescopic shock absorbers
Tata T.7 Ultra Twin Tyre Truck Rear Suspension
Rear Suspension
Semi elliptical leaf springs
With telescopic shock absorbers
Tata T.7 Ultra Twin Tyre Truck Tyres
Tyres
235/75 R 17.5
Tubeless Radial
6+1 tyres
Tata T.7 Ultra Twin Tyre Truck Wheelbase
Wheelbase
3550 mm
3920 mm
Tata T.7 Ultra Twin Tyre Truck Turning Circle Diameter
Turning Circle Diameter
13.9 m (3550 wb)
15.2 m (3920 wb)
Tata T.7 Ultra Twin Tyre Truck Ground Clearance
Ground Clearance
183 mm
Tata T.7 Ultra Twin Tyre Truck Overall Length
Overall Length
6400 mm (3550 wb HSD)
7305 mm (3920 wb HSD)
Tata T.7 Ultra Twin Tyre Truck Overall Width
Overall Width
2050 mm
Tata T.7 Ultra Twin Tyre Truck Overall Height
Overall Height
2630 mm (HSD)
Tata T.7 Ultra Twin Tyre Truck Load Body Width
Load Body Width
6.3 ft
Tata T.7 Ultra Twin Tyre Truck Chassis Thickness
Chassis Thickness
5 mm

Tata T.7 Ultra Twin Tyre Truck Specification Highlights

Let us take a look at some of the latest specifications of Tata T.7 Ultra twin tyre truck. The six wheeler Ultra Twin truck has an Delphi fuel injection type engine displacement of 2956 cc, which produces a power of 100 horsepower with torque of 300 Nm. The Tata T.7 Ultra twin tyre truck has a 5-speed gearbox transmission. New Tata T.7 Ultra twin tyre comes with a gross vehicle weight of 7490 kilogram. The 6 chakka Tata Ultra truck is equipped with the latest synchromesh gearbox G400. The Tata truck has a fuel tank capacity of 60 litres with a maximum speed of the truck is 80 kilometers per hour. If you want to go with this Ultra T.7 Twin Tyre then you should also check its next upcoming features in the table above.
