What is the engine capacity of BharatBenz 2826C tipper?

BharatBenz 2826C comes with 6 cylinder OM 926 engine and the engine displacement is 7200 cc

BharatBenz 2826C Tipper Specifications

Rate This Vehicle

From ₹ 41.64-51.99 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on BharatBenz 2826C Tipper for this month

BharatBenz 2826C - 10 Wheeler Tipper Highlights

Power

260

GVW

28000 Kg

Fuel

Diesel

Engine

7200 cc

Cylinders

Key Specifications of BharatBenz 2826C Tipper

Engine
Configuration

BharatBenz 2826C Tipper Engine
Engine
OM 926
BharatBenz 2826C Tipper Fuel Injection System
Fuel Injection System
Unitised fuel injection pump
BharatBenz 2826C Tipper Engine Displacement
Engine Displacement
7200 cc
BharatBenz 2826C Tipper Engine Cylinders
Engine Cylinders
6
BharatBenz 2826C Tipper Power
Power
260 HP@2200 rpm
BharatBenz 2826C Tipper Torque
Torque
900 Nm@1200-1600 rpm
BharatBenz 2826C Tipper Clutch
Clutch
430 mm dia, Single dry plate
With clutch booster
BharatBenz 2826C Tipper Transmission
Transmission
9 speed (9F+1R)
BharatBenz 2826C Tipper Gearbox
Gearbox
G131, Synchromesh
BharatBenz 2826C Tipper Gradeability
Gradeability
40%
BharatBenz 2826C Tipper Max Speed
Max Speed
60 Kmph
BharatBenz 2826C Tipper Emission Norms Compliance
Emission Norms Compliance
BS6 OBD2
BharatBenz 2826C Tipper Fuel Type
Fuel Type
Diesel
BharatBenz 2826C Tipper Fuel Tank Capacity
Fuel Tank Capacity
Diesel: 215/200 Litres
Ad Blue: 43 / 36 Litres
With diesel anti-theft strain
BharatBenz 2826C Tipper Electricals Battery
Electricals Battery
24V, 120 Ah

BharatBenz 2826C Tipper GVW
GVW
28000 Kg (Radial tyres)
27600 Kg (Nylon, Mining Tyre)
BharatBenz 2826C Tipper Vehicle Configuration
Vehicle Configuration
Cabin and chassis
Cabin with Box body
BharatBenz 2826C Tipper Load Body Options
Load Body Options
14 Cu.M Box body
16 Cu.M Box
BharatBenz 2826C Tipper Cabin Type
Cabin Type
Day cab
BharatBenz 2826C Tipper Cabin Tilt mechanism
Cabin Tilt mechanism
Hydraulically tiltable
BharatBenz 2826C Tipper Chassis Frame
Chassis Frame
Ladder type with cross members
BharatBenz 2826C Tipper Axle Configuration
Axle Configuration
6x4
BharatBenz 2826C Tipper Front Axle
Front Axle
IF 7.0 Reverse Elliot Type
BharatBenz 2826C Tipper Rear Axle
Rear Axle
RA1 IRT390-11
RA2 IRT390-11
BharatBenz 2826C Tipper Front Suspension
Front Suspension
Parabolic Type Leaf Spring
With Hydraulic Shock Absorbers
BharatBenz 2826C Tipper Rear Suspension
Rear Suspension
Bogie suspension
BharatBenz 2826C Tipper Anti Roll Bar
Anti Roll Bar
Front and Rear
BharatBenz 2826C Tipper Tyres
Tyres
Radial: 11R20
Nylon: 11x20
BharatBenz 2826C Tipper Wheelbase
Wheelbase
4275 mm
BharatBenz 2826C Tipper Turning Circle Diameter
Turning Circle Diameter
15.5 m
BharatBenz 2826C Tipper Ground Clearance
Ground Clearance
290 mm
BharatBenz 2826C Tipper Overall Length
Overall Length
7185 mm
BharatBenz 2826C Tipper Overall Width
Overall Width
2490 mm
BharatBenz 2826C Tipper Overall Height
Overall Height
2995 mm
BharatBenz 2826C Tipper Front Overhang
Front Overhang
1485 mm
BharatBenz 2826C Tipper Rear Overhang
Rear Overhang
750 mm
BharatBenz 2826C Tipper Chassis Depth
Chassis Depth
288 mm
BharatBenz 2826C Tipper Chassis Flange width
Chassis Flange width
70 mm
BharatBenz 2826C Tipper Chassis Thickness
Chassis Thickness
9 mm

BharatBenz 2826C Tipper Specification Highlights

Check all the BharatBenz 2826C specifications on TrucksBuses in the table aboveThe main driveline of this BharatBenz tipper includes a 6 cylinder OM 926 engine that produces a maximum power of 260 HP and a torque of 900 NmIt is matched with 9 speed (9F+1R), G131, Synchromesh gearbox A gross weight of 28000 kg (radial tyres), 27600 kg (nylon, mining tyre) and multiple body configurations allows the owner to carry multiple kinds of loads as per requirement, in this BharatBenz dumperBharatBenz 2826C tipper comes with a day cab with multiple utility features for driver comfort Other BharatBenz 2826C tipper specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the table above.
