What is the engine capacity of Tata Prima 3525.TK Bogie tipper?

Tata Prima 3525.TK Bogie comes with 6 cylinder Cummins ISBe 6.7L engine and the engine displacement is 6692 cc

What is Tata Prima 3525.TK Bogie gradeability ?

Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Tata Prima 3525.TK Bogie is .

Tata Prima 3525.TK Bogie BS6 Tipper Specifications

Rate This Vehicle

From ₹ 51.70-58.19 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata Prima 3525.TK Bogie Tipper for this month

Download Tata Prima 3525.TK Bogie Tipper Brochure

Check out the Tata Prima 3525.TK Bogie Tipper PDF brochure at TrucksBuses.com with all features and specifications.

Tata Prima 3525.TK Bogie - 12 Tyre Tipper Highlights

Power

250

GVW

35000 Kg

Fuel

Diesel

Engine

6692 cc

Cylinders

Key Specifications of Tata Prima 3525.TK Bogie Tipper

Engine
Configuration

Tata Prima 3525.TK Bogie Tipper Engine
Engine
Cummins ISBe 6.7L
Tata Prima 3525.TK Bogie Tipper Fuel Injection System
Fuel Injection System
Common Rail
Tata Prima 3525.TK Bogie Tipper Engine Displacement
Engine Displacement
6692 cc
Tata Prima 3525.TK Bogie Tipper Engine Cylinders
Engine Cylinders
6
Tata Prima 3525.TK Bogie Tipper Power
Power
250 HP@2300 rpm
Tata Prima 3525.TK Bogie Tipper Torque
Torque
950 Nm@1000-1700 rpm
Tata Prima 3525.TK Bogie Tipper Clutch
Clutch
430 mm dia
Organic
Tata Prima 3525.TK Bogie Tipper Transmission
Transmission
9 speed (9F+1R)
Tata Prima 3525.TK Bogie Tipper Gearbox
Gearbox
G1150
Tata Prima 3525.TK Bogie Tipper Emission Norms Compliance
Emission Norms Compliance
BS6
Tata Prima 3525.TK Bogie Tipper Fuel Type
Fuel Type
Diesel
Tata Prima 3525.TK Bogie Tipper Fuel Tank Capacity
Fuel Tank Capacity
300 Litres
Polymer tank
With anti-fuel theft

Tata Prima 3525.TK Bogie Tipper GVW
GVW
35000 Kg
Tata Prima 3525.TK Bogie Tipper Vehicle Configuration
Vehicle Configuration
Cabin with Box body
Tata Prima 3525.TK Bogie Tipper Load Body Options
Load Body Options
23 Cu.M Box body
Tata Prima 3525.TK Bogie Tipper Cabin Type
Cabin Type
Day Cab
Tata Prima 3525.TK Bogie Tipper Cabin Tilt mechanism
Cabin Tilt mechanism
Hydraulically tiltable
Tata Prima 3525.TK Bogie Tipper Chassis Frame
Chassis Frame
Ladder type straight frame
Tata Prima 3525.TK Bogie Tipper Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata Prima 3525.TK Bogie Tipper Rear Axle
Rear Axle
Single reduction, Hypoid gears, Fully Floating Axle
RA 109
Tata Prima 3525.TK Bogie Tipper Front Suspension
Front Suspension
Parabolic leaf springs
Tata Prima 3525.TK Bogie Tipper Rear Suspension
Rear Suspension
Bogie suspension
Tata Prima 3525.TK Bogie Tipper Anti Roll Bar
Anti Roll Bar
Yes
Tata Prima 3525.TK Bogie Tipper Tyres
Tyres
11R20
12+1 tyres
Tata Prima 3525.TK Bogie Tipper Wheelbase
Wheelbase
5250 mm

Tata Prima 3525.TK Bogie Tipper Specification Highlights

Explore now the latest specification of Tata Prima 3525.TK Bogie at TrucksBuses. The main driveline of this 12 wheeler Tata Tipper includes a 6 cylinders, cummins ISBE 6.7 L engine that produces 250 horsepower and 950 Nm of torque. The Tata 12 wheeler dumper matched with 9 speed G1150 gearbox. The new Prima 3525.TK bogie 12 chakka has a gross vehicle weight of 35000 kilogram. And allowing you to carry loads of multiple body configurations, this Tata dumper Prima 3525.TK Bogie comes with a day cab with multiple utility features. Other specifications of new Tata Prima 3525.TK Bogie tipper for driver comfort like cabin with Box body, hydraulically tiltable cabin, ladder type straight frame and parabolic leaf springs are given in the above table.
