Eicher Pro 6055 XP tractor trailer specifications

Rate This Vehicle

From ₹ 35.37 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Eicher Pro 6055 XP 6x4 Tractor for this month

Eicher Pro 6055 XP - 10 Wheel Horse Highlights

Power

296

GVW

55000 Kg

Fuel

Diesel

Engine

7698 cc

Cylinders

Key Specifications of Eicher Pro 6055 XP 6x4 Tractor

Engine
Configuration

Eicher Pro 6055 XP 6x4 Tractor Engine
Engine
VEDX8 - 7.7L
Eicher Pro 6055 XP 6x4 Tractor Fuel Injection System
Fuel Injection System
Common Rail
Eicher Pro 6055 XP 6x4 Tractor Engine Displacement
Engine Displacement
7698 cc
Eicher Pro 6055 XP 6x4 Tractor Engine Cylinders
Engine Cylinders
6
Eicher Pro 6055 XP 6x4 Tractor Power
Power
296 HP@2200 rpm
Eicher Pro 6055 XP 6x4 Tractor Torque
Torque
1200 Nm@1200-1600 rpm
Eicher Pro 6055 XP 6x4 Tractor Clutch
Clutch
430 mm dia
Eicher Pro 6055 XP 6x4 Tractor Transmission
Transmission
9 speed (8F+1CR+1R)
Eicher Pro 6055 XP 6x4 Tractor Gearbox
Gearbox
ET 140 S9
Eicher Pro 6055 XP 6x4 Tractor Gradeability
Gradeability
23%
Eicher Pro 6055 XP 6x4 Tractor Max Speed
Max Speed
80 Kmph
Eicher Pro 6055 XP 6x4 Tractor Emission Norms Compliance
Emission Norms Compliance
BS6 OBD2
Eicher Pro 6055 XP 6x4 Tractor Fuel Type
Fuel Type
Diesel
Eicher Pro 6055 XP 6x4 Tractor Fuel Tank Capacity
Fuel Tank Capacity
Diesel: 350 Litres
Ad Blue: 50 Litres
Eicher Pro 6055 XP 6x4 Tractor Electricals Battery
Electricals Battery
24V

Eicher Pro 6055 XP 6x4 Tractor Gross Combination Weight
Gross Combination Weight
55000 Kg
With 12 tyre trailer
Eicher Pro 6055 XP 6x4 Tractor Cabin Type
Cabin Type
Sleeper cabin
Eicher Pro 6055 XP 6x4 Tractor Cabin Tilt mechanism
Cabin Tilt mechanism
Hydraulically tiltable
Eicher Pro 6055 XP 6x4 Tractor Chassis Frame
Chassis Frame
Domex frame
Eicher Pro 6055 XP 6x4 Tractor Axle Configuration
Axle Configuration
6x4
Eicher Pro 6055 XP 6x4 Tractor Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Eicher Pro 6055 XP 6x4 Tractor Rear Axle
Rear Axle
Fully floating, Single reduction
Final Drive Ratio 5.29
Eicher Pro 6055 XP 6x4 Tractor Front Suspension
Front Suspension
Parabolic leaf spring
With shock absorbers
Eicher Pro 6055 XP 6x4 Tractor Rear Suspension
Rear Suspension
Bell crank suspension
Bogie suspension (Optional)
Eicher Pro 6055 XP 6x4 Tractor Tyres
Tyres
295/90R20
11R20 (Optional)
10+1 tyres
Eicher Pro 6055 XP 6x4 Tractor Wheelbase
Wheelbase
4050 mm (Bell crank)
4085 mm (Bogie)
Eicher Pro 6055 XP 6x4 Tractor Overall Length
Overall Length
7093 mm
Eicher Pro 6055 XP 6x4 Tractor Overall Width
Overall Width
2528 mm
Eicher Pro 6055 XP 6x4 Tractor Chassis Depth
Chassis Depth
300 mm
Eicher Pro 6055 XP 6x4 Tractor Chassis Flange width
Chassis Flange width
76 mm (Bell crank)
90 mm (Bogie)
Eicher Pro 6055 XP 6x4 Tractor Chassis Thickness
Chassis Thickness
7 mm (Bell crank)
8 mm (Bogie)

Eicher Pro 6055 XP 6x4 Tractor Specification Highlights

Let us explain the engine performance and body configuration of the Eicher Pro 6055 XP 6x4 tractor trailer. The gross vehicle weight of the Eicher Pro 6055 XP 6x4 tractor trailer is 55000 kilograms. This 10-chakka tractor trailer is empowered by a 6-cylinder VEDX8 - 7.7L powerful engine of 7698 cc. It produces a power of 296 horsepower and a maximum torque of 1200 Nm. This tractor-trailer is available in an axle configuration of 6x4. The power transmission of the Eicher Pro 6055 XP tractor-trailer is managed by a 9-speed gearbox system. The front and rear suspensions are coupled with parabolic leaf springs with shock absorbers and bell crank suspension. The wheelbase size of the Pro 6055 XP tractor trailer is 4050 mm and the tyre size is 295/90R20 offering a 304 mm ground clearance. It comes with a sleeper-type cabin. The Eicher Pro 6055 XP tractor-trailer comes under the BS6 OBD2 emission norms. Some other configurations are mentioned in the table above.

Frequently Asked Questions on Eicher Pro 6055 XP 6x4 Tractor

What is the engine capacity of Eicher Pro 6055 XP tractor trailer ?

Eicher Pro 6055 XP comes with 6 cylinder VEDX8 - 7.7L engine and the engine displacement is 7698 cc

What is Eicher Pro 6055 XP power and torque ?

In terms of performance, Eicher Pro 6055 XP produces a maximum power of 296 HP@2200 rpm and a maximum torque of 1200 Nm@1200-1600 rpm

What is the gearbox and transmission type in Eicher Pro 6055 XP tractor trailer ?

Eicher Pro 6055 XP comes with a 9 speed (8F+1CR+1R) transmission along with a 430 mm dia clutch

What is the fuel tank capacity of Eicher Pro 6055 XP ?

Eicher Pro 6055 XP comes with Diesel fuel option and its fuel tank capacity is Diesel: 350 Litres# Ad Blue: 50 Litres

What is Eicher Pro 6055 XP gradeability ?

Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Eicher Pro 6055 XP is 23%.

What is Eicher Pro 6055 XP tyre size ?

The tyre size of Eicher Pro 6055 XP is 295/90R20# 11R20 (Optional)# 10+1 tyres

What is the type of brakes offered in Eicher Pro 6055 XP ?

Eicher Pro 6055 XP comes with Air brakes

What is the warranty offered in Eicher Pro 6055 XP ?

Eicher Pro 6055 XP tipper comes with a standard warranty of 4 years unlimited km on driveline

What is the EMI of Eicher Pro 6055 XP ?

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Eicher Pro 6055 XP is expected to be around Rs Not Available for a 5 year period
