Man CLA 49.250 EVO 6x4 Specifications

Rate This Vehicle

*Ex - showroom Price of Man CLA 49.250 EVO 6x4 is 30.10-32.50 Lakh*

From ₹ 30.10-32.50 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Man CLA 49.250 EVO 6x4 for this month

Man CLA 49.250 EVO 6x4 - 10 Tyre Tractor Highlights

Power

Man CLA 49.250 EVO 6x4 Power

255
GVW

Man CLA 49.250 EVO 6x4 GVW

49000 Kg
Fuel

Man CLA 49.250 EVO 6x4 Fuel

Diesel
Engine

Man CLA 49.250 EVO 6x4 Engine

6900 cc
Cylinders

Man CLA 49.250 EVO 6x4 Cylinders

6
Trucksbuses.com
Trucksbuses.com

Key Specifications of Man CLA 49.250 EVO 6x4

  • Engine
    Man D-0836
  • Fuel Injection System
    Common Rail
  • Engine Displacement
    6900 cc
  • Engine Cylinders
    6
  • Power
    255 HP@2300 rpm
  • Torque
    950 Nm@1100-1850 rpm
  • Clutch
    Single plate, Power assisted
  • Transmission
    9 Speed (9F+1R)
  • Gearbox
    Synchromesh
  • Gradeability
    18% (First gear)
    27% (Crawler gear)
  • Max Speed
    80 Kmph
  • Emission Norms Compliance
    BS4
  • Fuel Type
    Diesel
  • Fuel Tank Capacity
    300 Litres
  • Electricals Battery
    2x12 V, 100 Ah
  • Gross Combination Weight
    49000 Kg
  • Kerb Weight
    7900 Kg
  • Cabin Type
    Sleeper cab
  • Cabin Tilt mechanism
    Hydraulically tiltable
  • Chassis Frame
    C channel rolled section
  • Axle Configuration
    6x2
  • Front Axle
    Forged I-Beam type, Maintence free Hub Bearings
  • Rear Axle
    Fully floating single speed hypoid axle
  • Front Suspension
    Parabolic leaf springs
    With double acting shock absorbers
  • Rear Suspension
    Bell crank suspension
  • Tyres
    11x20
  • Wheelbase
    3890 mm
  • Ground Clearance
    292 mm (Front)
    272 mm (Rear)
  • Overall Length
    6630 mm
  • Overall Height
    2786 mm
  • Front Overhang
    1300 mm
  • Rear Overhang
    725 mm
  • Front Track
    2075 mm
  • Rear Track
    1818 mm

Man CLA 49.250 EVO 6x4 Specification Highlights

Browsing the engine performance and the body configuration of the latest Man CLA 49.250 EVO 6x4 tractor-trailer here. The 10-wheeler Man CLA 49.250 EVO is empowered by a Man D-0836 powerful engine of 6900 cc displacement which produces a high-end torque of 950 Nm and a power of 255 horsepower. This 10-wheeler Man CLA tractor-trailer power transmission is controlled by a 9-speed synchromesh gearbox system. Its gradeability is 18% and 27%. The latest Man CLA tractor-trailer follows BS4 emission norms. It comes with a fuel tank of a capacity of 300 liters. The latest tractor-trailer Man CLA 49.250 EVO has a C-channel rolled section chassis frame and an axle configuration of 6x4. The day-cab type hydraulically tiltable sleeper cabin is provided for this tractor-trailer. The front suspension has parabolic leaf springs with double acting shock absorbers and bell crank rear suspension. The wheelbase and tyre size of this 10-chakka tractor-trailer is 3890 mm and 11x20 respectively. A few configurations of this Man CLA tractor-trailer are described above in the table.

Frequently Asked Questions on Man CLA 49.250 EVO 6x4

Man CLA 49.250 EVO 6x4 comes with a 9 Speed (9F+1R) transmission along with a Single plate, Power assisted clutch

Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Man CLA 49.250 EVO 6x4 is 18% (First gear)# 27% (Crawler gear).

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Man CLA 49.250 EVO 6x4 is expected to be around Rs Not Available for a 5 year period

Man CLA 49.250 EVO 6x4 comes with 6 cylinder Man D-0836 engine and the engine displacement is 6900 cc

In terms of performance, Man CLA 49.250 EVO 6x4 produces a maximum power of 255 HP@2300 rpm and a maximum torque of 950 Nm@1100-1850 rpm

Man CLA 49.250 EVO 6x4 comes with Diesel fuel option and its fuel tank capacity is 300 Litres

The tyre size of Man CLA 49.250 EVO 6x4 is 11x20

Man CLA 49.250 EVO 6x4 comes with Air brakes# Electronic Brake System (EBS)
