What is the latest Tata LP 1512 bus price in India ?

Tata LP 1512 bus chassis price starts from Rs 0. The 2023 price of Tata LP 1512 bus chassis can vary slightly from state to state and city to city.

What is the gearbox and transmission type in Tata LP 1512 bus chassis ?

Tata LP 1512 bus comes with a transmission

Tata LP 1512 bus specifications

Q: What is the engine capacity of Tata LP 1512 bus?

Tata LP 1512 bus chassis comes with 6 cylinder Cummins ISBe 5.9 CRDi# SCR Technologyengine and the engine displacement is 5883 cc

Rate This Vehicle

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata LP 1512 Bus Chassis for this month

Tata LP 1512 - 6 Wheeler Bus Highlights

Power

135

GVW

16200 Kg

Fuel

Diesel

Engine

5883 cc

Cylinders

Key Specifications of Tata LP 1512 Bus Chassis

Engine
Configuration

Tata LP 1512 Bus Chassis Engine
Engine
Cummins ISBe 5.9 CRDi
SCR Technology
Tata LP 1512 Bus Chassis Fuel Injection System
Fuel Injection System
Common Rail
Tata LP 1512 Bus Chassis Engine Displacement
Engine Displacement
5883 cc
Tata LP 1512 Bus Chassis Engine Cylinders
Engine Cylinders
6
Tata LP 1512 Bus Chassis Engine Location
Engine Location
Front
Tata LP 1512 Bus Chassis Power
Power
135 HP@2500 rpm
Tata LP 1512 Bus Chassis Torque
Torque
430 Nm@1500 rpm
Tata LP 1512 Bus Chassis Clutch
Clutch
330 mm dia
Organic
Tata LP 1512 Bus Chassis Gearbox
Gearbox
G40 synchromesh
Tata LP 1512 Bus Chassis Gradeability
Gradeability
21%
Tata LP 1512 Bus Chassis Max Speed
Max Speed
80 kmph
Tata LP 1512 Bus Chassis Emission Norms Compliance
Emission Norms Compliance
BSIV
Tata LP 1512 Bus Chassis Fuel Type
Fuel Type
Diesel
Tata LP 1512 Bus Chassis Fuel Tank Capacity
Fuel Tank Capacity
250 Litres
Tata LP 1512 Bus Chassis Electricals Battery
Electricals Battery
2x12 Volts, 150 Ah
Alternator: 45 Amps

Tata LP 1512 Bus Chassis GVW
GVW
16200 Kg
Tata LP 1512 Bus Chassis Overall Length
Overall Length
7380 mm (4225 wb)
9495 mm (5195 wb)
Tata LP 1512 Bus Chassis Chassis Frame
Chassis Frame
Ladder type with rivetted / bolted cross members
Tata LP 1512 Bus Chassis Axle Configuration
Axle Configuration
4x2
Tata LP 1512 Bus Chassis Rear Axle
Rear Axle
Single reduction hypoid gears
Fully floating axle shafts
Tata LP 1512 Bus Chassis Front Suspension
Front Suspension
Semi elliptical leaf springs
With telescopic shock absorbers
Tata LP 1512 Bus Chassis Rear Suspension
Rear Suspension
Semi elliptical leaf springs
With telescopic shock absorbers
Tata LP 1512 Bus Chassis Anti Roll Bar
Anti Roll Bar
Front only
Tata LP 1512 Bus Chassis Tyres
Tyres
10R20 - 16PR
Radial tyre
Tata LP 1512 Bus Chassis Wheelbase
Wheelbase
4225 mm
5195 mm
Tata LP 1512 Bus Chassis Turning Circle Diameter
Turning Circle Diameter
16.8 m (4225 wb)
20.3 m (5195 wb)
Tata LP 1512 Bus Chassis Ground Clearance
Ground Clearance
276 mm
Tata LP 1512 Bus Chassis Front Overhang
Front Overhang
1185 mm
Tata LP 1512 Bus Chassis Rear Overhang
Rear Overhang
1970 mm (4225 wb)
3115 mm (5195 wb)
Tata LP 1512 Bus Chassis Front Track
Front Track
1926 mm
Tata LP 1512 Bus Chassis Rear Track
Rear Track
1809 mm

Tata LP 1512 Bus Chassis Specification Highlights

Check all the Tata LP 1512 bus specifications here on TrucksBuses The main driveline of this Tata bus chassis includes a 6 cylinder Cummins ISBe 5.9 CRDi, SCR Technology engine that produces a maximum power of 135 HP and a torque of 430 NmTata LP 1512 bus comes with a gross vehicle weight of 16200 kg and offers length of 7380 mm (4225 wb), 9495 mm (5195 wb) For the comfortable journeys, semi elliptical leaf springs, with telescopic shock absorbers in front and semi elliptical leaf springs, with telescopic shock absorbers in rear does the duty in this Tata bus chassis Other Tata LP 1512 bus specifications like chassis, width, tyre, turning circle dia are available here in the tables on this page.
