Tata Ace Gold Petrol CX specifications

Tata Ace Gold Petrol CX Mini Truck Images

Rate This Vehicle

From ₹ 4.21 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata Ace Gold Petrol CX Mini Truck for this month

Download Tata Ace Gold Petrol CX Mini Truck Brochure

Check out the Tata Ace Gold Petrol CX Mini Truck PDF brochure at TrucksBuses.com with all features and specifications.

Tata Ace Gold Petrol CX - 4 Wheeler Highlights

Power

GVW

1615 Kg

Fuel

Petrol

Engine

694 cc

Cylinders

Key Specifications of Tata Ace Gold Petrol CX Mini Truck

Engine
Configuration

Tata Ace Gold Petrol CX Mini Truck Engine
Engine
275 Gasoline MPFI; 4 Stroke Water cooled
Tata Ace Gold Petrol CX Mini Truck Engine Displacement
Engine Displacement
694 cc
Tata Ace Gold Petrol CX Mini Truck Engine Cylinders
Engine Cylinders
2
Tata Ace Gold Petrol CX Mini Truck Power
Power
25 HP
Tata Ace Gold Petrol CX Mini Truck Torque
Torque
55 Nm
Tata Ace Gold Petrol CX Mini Truck Clutch
Clutch
Single plate dry clutch
Tata Ace Gold Petrol CX Mini Truck Transmission
Transmission
4 speed (4F+1R)
Tata Ace Gold Petrol CX Mini Truck Gearbox
Gearbox
GBS 65 Synchromesh
Tata Ace Gold Petrol CX Mini Truck Gradeability
Gradeability
29%
Tata Ace Gold Petrol CX Mini Truck Max Speed
Max Speed
70 Kmph
Tata Ace Gold Petrol CX Mini Truck Emission Norms Compliance
Emission Norms Compliance
BS6
Tata Ace Gold Petrol CX Mini Truck Fuel Type
Fuel Type
Petrol
Tata Ace Gold Petrol CX Mini Truck Fuel Tank Capacity
Fuel Tank Capacity
26 Litres

Tata Ace Gold Petrol CX Mini Truck GVW
GVW
1615 Kg
Tata Ace Gold Petrol CX Mini Truck Payload
Payload
710 Kg
Tata Ace Gold Petrol CX Mini Truck Vehicle Configuration
Vehicle Configuration
Cabin with Fixed Side Deck body
Cabin with Flat bed
Tata Ace Gold Petrol CX Mini Truck Seating Capacity
Seating Capacity
D+1
Tata Ace Gold Petrol CX Mini Truck Axle Configuration
Axle Configuration
4x2
Tata Ace Gold Petrol CX Mini Truck Front Suspension
Front Suspension
Rigid axle with parabolic leaf spring
Tata Ace Gold Petrol CX Mini Truck Rear Suspension
Rear Suspension
Semi elliptical leaf spring
Tata Ace Gold Petrol CX Mini Truck Anti Roll Bar
Anti Roll Bar
No
Tata Ace Gold Petrol CX Mini Truck Tyres
Tyres
145 R12 LT- 8PR
Tata Ace Gold Petrol CX Mini Truck Wheelbase
Wheelbase
2100 mm
Tata Ace Gold Petrol CX Mini Truck Turning Circle Diameter
Turning Circle Diameter
8.6 m
Tata Ace Gold Petrol CX Mini Truck Ground Clearance
Ground Clearance
160 mm
Tata Ace Gold Petrol CX Mini Truck Overall Length
Overall Length
3800 mm
Tata Ace Gold Petrol CX Mini Truck Overall Width
Overall Width
1500 mm
Tata Ace Gold Petrol CX Mini Truck Overall Height
Overall Height
1840 mm
Tata Ace Gold Petrol CX Mini Truck Front Track
Front Track
1300 mm
Tata Ace Gold Petrol CX Mini Truck Rear Track
Rear Track
1320 mm
Tata Ace Gold Petrol CX Mini Truck Load Body Dimensions
Load Body Dimensions
7.2 x 4.9 ft

Tata Ace Gold Petrol CX Mini Truck Specification Highlights

The new Tata Ace Gold Petrol Cx specs give us an insight into the engine and configuration of the mini truck. The 4-tyre Tata Ace Gold Petrol Cx has a gross vehicle weight of 1615 kilograms and consists of a single plate dry clutch with 2 engine cylinders. The Tata mini truck has a GBS 65 synchromesh gearbox and 29% gradeability. It also follows BS6 emission norms, which is essential. It can run at a maximum speed of 70 kilometers per hour with a 4-speed gearbox system. The vehicle has two configurations, one is a cabin with a fixed side deck body, while the other is a cabin with a flatbed, which makes it quite convenient for use. You can check more Tata Ace Gold Petrol Cx specifications in the above table.
