What is Tata Winger Cargo gradeability ?

Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Tata Winger Cargo is .

Tata Winger Cargo specifications

Rate This Vehicle

From ₹ 13.3 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata Winger Cargo Van for this month

Download Tata Winger Cargo Van Brochure

Check out the Tata Winger Cargo Van PDF brochure at TrucksBuses.com with all features and specifications.

Tata Winger Cargo - 4 Wheeler Highlights

Power

100

GVW

3490 Kg

Fuel

Diesel

Engine

2179 cc

Cylinders

Key Specifications of Tata Winger Cargo Van

Engine
Configuration

Tata Winger Cargo Van Engine
Engine
2.2L DICOR
With LNT Technology
Tata Winger Cargo Van Engine Displacement
Engine Displacement
2179 cc
Tata Winger Cargo Van Engine Cylinders
Engine Cylinders
4
Tata Winger Cargo Van Power
Power
100 HP@3750 rpm
Tata Winger Cargo Van Torque
Torque
200 Nm@1000-3500 rpm
Tata Winger Cargo Van Clutch
Clutch
215 mm dia dry friction
Tata Winger Cargo Van Transmission
Transmission
5 speed (5F+1R)
Tata Winger Cargo Van Gearbox
Gearbox
Transaxle with Synchromesh gears
Tata Winger Cargo Van Max Speed
Max Speed
80 Kmph
Tata Winger Cargo Van Emission Norms Compliance
Emission Norms Compliance
BS6
Tata Winger Cargo Van Fuel Type
Fuel Type
Diesel
Tata Winger Cargo Van Fuel Tank Capacity
Fuel Tank Capacity
60 Litres

Tata Winger Cargo Van GVW
GVW
3490 Kg
Tata Winger Cargo Van Payload
Payload
1680 Kg
Tata Winger Cargo Van Vehicle Configuration
Vehicle Configuration
Closed cargo van
Tata Winger Cargo Van Seating Capacity
Seating Capacity
D+2
Tata Winger Cargo Van Axle Configuration
Axle Configuration
4x2
Front wheel drive
Tata Winger Cargo Van Front Axle
Front Axle
Independent with CV Shaft
Tata Winger Cargo Van Rear Axle
Rear Axle
Dead axle
Tata Winger Cargo Van Front Suspension
Front Suspension
McPherson struts with coil spring
Tata Winger Cargo Van Rear Suspension
Rear Suspension
Parabolic Leaf Spring
With telescopic shock absorbers
Tata Winger Cargo Van Anti Roll Bar
Anti Roll Bar
Front & Rear
Tata Winger Cargo Van Tyres
Tyres
195 R15 LT
Tata Winger Cargo Van Wheelbase
Wheelbase
3488 mm
Tata Winger Cargo Van Turning Circle Diameter
Turning Circle Diameter
13.5 m
Tata Winger Cargo Van Ground Clearance
Ground Clearance
185 mm
Tata Winger Cargo Van Overall Length
Overall Length
5458 mm
Tata Winger Cargo Van Overall Width
Overall Width
1905 mm
Tata Winger Cargo Van Overall Height
Overall Height
2460 mm
Tata Winger Cargo Van Front Track
Front Track
1560 mm
Tata Winger Cargo Van Rear Track
Rear Track
1560 mm
Tata Winger Cargo Van Load Body Dimensions
Load Body Dimensions
10 x 5.5 ft

Tata Winger Cargo Van Specification Highlights

Let us check out the latest specifications of the Tata Winger Cargo van. The brand new Tata Winger has a 2.2L DICOR engine with LNT technology engine which comes with an engine displacement of 2179 cc, producing 100 horsepower. The Tata Winger Cargo with a 4-cylinder engine has gross vehicle weight is 3.49 tonnes. The payload capacity of Tata Winger van is 1680 kilograms. The Winger van has a 5-speed transmission with transaxle and synchromesh gears. The Tata Winger has a diesel fuel tank capacity of 60 litres. Here you can find the other latest specifications of the Tata Cargo van such as cabin type, chassis frame, axle configuration and tyres in the table above.
