Ashok Leyland Boss 1115 HB Truck GVW
GVW 11120 Kg
Ashok Leyland Boss 1115 HB Truck Vehicle Configuration
Vehicle Configuration Cabin and chassis
Cabin with load body
Ashok Leyland Boss 1115 HB Truck Load Body Options
Load Body Options Fixed Side Deck
Drop Side Deck
High Side Deck
Ashok Leyland Boss 1115 HB Truck Loading Span
Loading Span 14 ft
17 ft
20 ft
22 ft
Ashok Leyland Boss 1115 HB Truck Cabin Type
Cabin Type Day cab
With sleeping provision
Ashok Leyland Boss 1115 HB Truck Cabin Tilt mechanism
Cabin Tilt mechanism Hydraulically tiltable
Ashok Leyland Boss 1115 HB Truck Chassis Frame
Chassis Frame Ladder type
Ashok Leyland Boss 1115 HB Truck Axle Configuration
Axle Configuration 4x2
Ashok Leyland Boss 1115 HB Truck Front Axle
Front Axle Forged I Beam, Reverse Elliot Type
Ashok Leyland Boss 1115 HB Truck Rear Axle
Rear Axle Fully floating single speed
Hypoid axle
RAR 4.56
Ashok Leyland Boss 1115 HB Truck Front Suspension
Front Suspension Parabolic leaf springs
With telescopic shock absorbers
Ashok Leyland Boss 1115 HB Truck Rear Suspension
Rear Suspension Semi elliptical leaf springs
Ashok Leyland Boss 1115 HB Truck Anti Roll Bar
Anti Roll Bar Front
Ashok Leyland Boss 1115 HB Truck Tyres
Tyres 235/75R 17.5 (Tubeless)
8.25x16-16 PR (Optional)
6+1 tyres
Ashok Leyland Boss 1115 HB Truck Wheelbase
Wheelbase 3440 mm
3940 mm
4540 mm
4940 mm
Ashok Leyland Boss 1115 HB Truck Turning Circle Diameter
Turning Circle Diameter 11.9 m (3440 wb)
14 m (3940 wb)
16.5 m (4540 wb)
17.2 m (4940 wb)
Ashok Leyland Boss 1115 HB Truck Ground Clearance
Ground Clearance 178 mm
Ashok Leyland Boss 1115 HB Truck Overall Length
Overall Length 6471 mm (14 ft body)
7450 mm (17 ft)
8248 mm (20 ft)
8935 mm (22 ft)
Ashok Leyland Boss 1115 HB Truck Overall Width
Overall Width 2340 mm (body)
Ashok Leyland Boss 1115 HB Truck Overall Height
Overall Height 2498 mm
Ashok Leyland Boss 1115 HB Truck Front Track
Front Track 1885 mm
Ashok Leyland Boss 1115 HB Truck Rear Track
Rear Track 1670 mm
Ashok Leyland Boss 1115 HB Truck Chassis Depth
Chassis Depth 200 mm (202 mm for 4940 wb)
Ashok Leyland Boss 1115 HB Truck Chassis Flange width
Chassis Flange width 60 mm (61 mm for 4940 wb)
Ashok Leyland Boss 1115 HB Truck Chassis Thickness
Chassis Thickness 5 mm (6 mm for 4940 wb)
