Tata LPT 407 Ex Hymiler truck specifications

Rate This Vehicle

From ₹ 15.20-18.50 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata LPT 407 Ex Hymiler Truck for this month

Download Tata LPT 407 Ex Hymiler Truck Brochure

Check out the Tata LPT 407 Ex Hymiler Truck PDF brochure at TrucksBuses.com with all features and specifications.

Tata LPT 407 Ex Hymiler - 4 Tyre Truck Highlights

Power

GVW

6250 Kg

Fuel

Diesel

Engine

2956 cc

Cylinders

Key Specifications of Tata LPT 407 Ex Hymiler Truck

Engine
Configuration

Tata LPT 407 Ex Hymiler Truck Engine
Engine
4SP CR
Turbo Intercooled
Tata LPT 407 Ex Hymiler Truck Fuel Injection System
Fuel Injection System
Common Rail
Electronic Delphi
Tata LPT 407 Ex Hymiler Truck Engine Displacement
Engine Displacement
2956 cc
Tata LPT 407 Ex Hymiler Truck Engine Cylinders
Engine Cylinders
4
Tata LPT 407 Ex Hymiler Truck Power
Power
85 HP@ 2800 rpm
Tata LPT 407 Ex Hymiler Truck Torque
Torque
250 Nm@1400-2400 rpm
Tata LPT 407 Ex Hymiler Truck Clutch
Clutch
280 mm dia
Tata LPT 407 Ex Hymiler Truck Transmission
Transmission
5 speed manual (5F+1R)
Tata LPT 407 Ex Hymiler Truck Gearbox
Gearbox
GBS 27, Synchromesh type
Tata LPT 407 Ex Hymiler Truck Gradeability
Gradeability
27%
Tata LPT 407 Ex Hymiler Truck Max Speed
Max Speed
80 Kmph
Tata LPT 407 Ex Hymiler Truck Emission Norms Compliance
Emission Norms Compliance
BSIV
Tata LPT 407 Ex Hymiler Truck Fuel Type
Fuel Type
Diesel
Tata LPT 407 Ex Hymiler Truck Fuel Tank Capacity
Fuel Tank Capacity
60 Litres
Tata LPT 407 Ex Hymiler Truck Electricals Battery
Electricals Battery
12V, 75 Ah
Alternator: 75 Amps

Tata LPT 407 Ex Hymiler Truck GVW
GVW
6250 Kg
Tata LPT 407 Ex Hymiler Truck Kerb Weight
Kerb Weight
2880 Kg (FSD)
3150 Kg (HSD)
Tata LPT 407 Ex Hymiler Truck Vehicle Configuration
Vehicle Configuration
Cabin and chassis
Cabin with load body options
Tata LPT 407 Ex Hymiler Truck Loading Span
Loading Span
14.2 ft
Tata LPT 407 Ex Hymiler Truck Cabin Type
Cabin Type
Day cab
Tata LPT 407 Ex Hymiler Truck Cabin Tilt mechanism
Cabin Tilt mechanism
Manually tiltable
Tata LPT 407 Ex Hymiler Truck Chassis Frame
Chassis Frame
Ladder type with cross members
Tata LPT 407 Ex Hymiler Truck Axle Configuration
Axle Configuration
4x2
Tata LPT 407 Ex Hymiler Truck Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata LPT 407 Ex Hymiler Truck Rear Axle
Rear Axle
Fully Floating, Single reduction hypoid gears
Tata LPT 407 Ex Hymiler Truck Front Suspension
Front Suspension
Semi-elliptical leaf springs
With telescopic shock absorbers
Tata LPT 407 Ex Hymiler Truck Rear Suspension
Rear Suspension
Semi-elliptical leaf springs
With auxiliary springs
With telescopic shock absorbers
Tata LPT 407 Ex Hymiler Truck Tyres
Tyres
8.25x16â€“16 PR
4+1 tyres
Tata LPT 407 Ex Hymiler Truck Wheelbase
Wheelbase
3400 mm
Tata LPT 407 Ex Hymiler Truck Turning Circle Diameter
Turning Circle Diameter
12.3 m
Tata LPT 407 Ex Hymiler Truck Ground Clearance
Ground Clearance
230 mm
Tata LPT 407 Ex Hymiler Truck Overall Length
Overall Length
5955 mm (HSD)
Tata LPT 407 Ex Hymiler Truck Overall Width
Overall Width
2198 mm (HSD)
2140 mm (FSD)
Tata LPT 407 Ex Hymiler Truck Overall Height
Overall Height
2830 mm (HSD)
Tata LPT 407 Ex Hymiler Truck Load Body Width
Load Body Width
2255 mm (7.4 ft)
Tata LPT 407 Ex Hymiler Truck Front Overhang
Front Overhang
1275 mm
Tata LPT 407 Ex Hymiler Truck Rear Overhang
Rear Overhang
1150 mm

Tata LPT 407 Ex Hymiler Truck Specification Highlights

Check all the Tata LPT 407 Ex Hymiler specifications on TrucksBuses in the table above The main driveline of this Tata truck includes a 2956 cc 4 cylinder engine that produces a maximum power of 85 HP and a torque of 250 Nm It gets mated to 5 speed manual (5F+1R), GBS 27, Synchromesh type gearbox A gross weight of 6250 kg and multiple configurations allows the owner to carry multiple kinds of goods as per requirement There are multiple features in this Tata truck for enhancing driver comfort Other Tata LPT 407 Ex Hymiler truck specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the tables above.
