Tata Ultra 1921.T truck specifications

Name: Tata Ultra 1921.T
Brand: Tata
SKU: TBN-20-0C24F1

Rate This Vehicle

From ₹ 25.10-26.10 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata Ultra 1921.T Truck for this month

Tata Ultra 1921.T - 6 Tyre Truck Highlights

Power

210

GVW

18500 Kg

Fuel

Diesel

Engine

5005 cc

Cylinders

Key Specifications of Tata Ultra 1921.T Truck

Engine
Configuration

Tata Ultra 1921.T Truck Engine
Engine
5L Turbotronn 2.0
Tata Ultra 1921.T Truck Fuel Injection System
Fuel Injection System
Common Rail
Tata Ultra 1921.T Truck Engine Displacement
Engine Displacement
5005 cc
Tata Ultra 1921.T Truck Engine Cylinders
Engine Cylinders
4
Tata Ultra 1921.T Truck Power
Power
210 HP
Tata Ultra 1921.T Truck Torque
Torque
700 Nm
Tata Ultra 1921.T Truck Clutch
Clutch
380 mm dia
Tata Ultra 1921.T Truck Transmission
Transmission
6 speed (6F+1R)
Dashboard mounted gear lever
Tata Ultra 1921.T Truck Gearbox
Gearbox
Synchromesh
Tata Ultra 1921.T Truck Max Speed
Max Speed
80 Kmph
Tata Ultra 1921.T Truck Emission Norms Compliance
Emission Norms Compliance
BS6 OBD2
Tata Ultra 1921.T Truck Fuel Type
Fuel Type
Diesel
Tata Ultra 1921.T Truck Fuel Tank Capacity
Fuel Tank Capacity
365 Litres
365+365 Litres (32 ft)
Polymer tank
With anti-fuel theft

Tata Ultra 1921.T Truck GVW
GVW
18500 Kg
Tata Ultra 1921.T Truck Payload
Payload
11.5-12 Tons*
Tata Ultra 1921.T Truck Vehicle Configuration
Vehicle Configuration
Cabin and chassis
Cabin with load body
Tata Ultra 1921.T Truck Load Body Options
Load Body Options
Fixed Side Deck
High Side Deck
Container
Tata Ultra 1921.T Truck Loading Span
Loading Span
18 ft
20 ft
24 ft
32 ft
Tata Ultra 1921.T Truck Cabin Type
Cabin Type
Sleeper cabin
Tata Ultra 1921.T Truck Cabin Tilt mechanism
Cabin Tilt mechanism
Hydraulically tiltable
Tata Ultra 1921.T Truck Chassis Frame
Chassis Frame
Ladder type straight frame
Tata Ultra 1921.T Truck Axle Configuration
Axle Configuration
4x2
Tata Ultra 1921.T Truck Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata Ultra 1921.T Truck Rear Axle
Rear Axle
Single reduction RA 110LD
RAR: 4.88 / 5.12 (68 wheelbase)
Tata Ultra 1921.T Truck Front Suspension
Front Suspension
Parabolic leaf springs
Tata Ultra 1921.T Truck Rear Suspension
Rear Suspension
Semi elliptical leaf springs
Bell crank
Tata Ultra 1921.T Truck Tyres
Tyres
295/90R20 (Tube)
10+1 tyres
Tata Ultra 1921.T Truck Wheelbase
Wheelbase
4225 mm
4855 mm
5195 mm
6750 mm
Tata Ultra 1921.T Truck Overall Length
Overall Length
7380 mm (4225 wb)
9495 mm (5195 mm)
Tata Ultra 1921.T Truck Chassis Depth
Chassis Depth
250 mm
Tata Ultra 1921.T Truck Chassis Flange width
Chassis Flange width
65 mm
Tata Ultra 1921.T Truck Chassis Thickness
Chassis Thickness
7 mm

Tata Ultra 1921.T Truck Specification Highlights

This tab lists all the specifications for the Tata Ultra 1921.T truck CNG cargo truck. The Tata Ultra 1921.T truck CNG features a 5005 cc diesel engine with a 4-cylinder diesel engine generating 210 HP of power and a torque of 700 Nm. It is equipped with a 6-speed synchromesh gearbox. The truck has a fuel tank capacity of 365 liters and meets BS6 OBD2 emission standards. The trucks configuration consists of a cabin with a load body and a cabin with chassis. It has a ladder-type straight chassis frame. The front and rear suspensions use parabolic leaf springs and semi-elliptical leaf springs with bell cranks. The Tata Ultra 1921.T truck is fitted with tyres sized 295/90R20 and has a wheelbase of 4225 mm, 4855 mm, 5195 mm, and 6750 mm.
