Tata Ultra Ex 1918.T Truck GVW
GVW 18500 Kg
Tata Ultra Ex 1918.T Truck Vehicle Configuration
Vehicle Configuration Cabin and chassis
Cabin with load body
Tata Ultra Ex 1918.T Truck Load Body Options
Load Body Options Fixed Side Deck
High Side Deck
Container
Tata Ultra Ex 1918.T Truck Loading Span
Loading Span 17 ft
20 ft
22 ft
24 ft
32 ft
Tata Ultra Ex 1918.T Truck Cabin Type
Cabin Type Sleeper cabin
Day cab (Optional)
Tata Ultra Ex 1918.T Truck Cabin Tilt mechanism
Cabin Tilt mechanism Hydraulically tiltable
Tata Ultra Ex 1918.T Truck Chassis Frame
Chassis Frame Ladder type straight frame
Tata Ultra Ex 1918.T Truck Axle Configuration
Axle Configuration 4x2
Tata Ultra Ex 1918.T Truck Front Axle
Front Axle Forged I Beam, Reverse Elliot Type
Tata Ultra Ex 1918.T Truck Rear Axle
Rear Axle Single reduction RA 1085RR
RAR 4.44
Tata Ultra Ex 1918.T Truck Front Suspension
Front Suspension Parabolic leaf springs
Tata Ultra Ex 1918.T Truck Rear Suspension
Rear Suspension Semi elliptical leaf springs
Tata Ultra Ex 1918.T Truck Anti Roll Bar
Anti Roll Bar Front only
Tata Ultra Ex 1918.T Truck Tyres
Tyres 295/90R20 (Tube)
6+1 tyres
Tata Ultra Ex 1918.T Truck Wheelbase
Wheelbase 3920 mm
4530 mm
4920 mm
5300 mm
5560 mm
6800 mm
Tata Ultra Ex 1918.T Truck Turning Circle Diameter
Turning Circle Diameter 23 m
Tata Ultra Ex 1918.T Truck Overall Length
Overall Length 8880 mm (4920 wb)
9510 mm (5300 wb)
11990 mm (6800 wb)
Tata Ultra Ex 1918.T Truck Load Body Width
Load Body Width 2285 mm
Tata Ultra Ex 1918.T Truck Front Track
Front Track 1933 mm
Tata Ultra Ex 1918.T Truck Rear Track
Rear Track 1809 mm
Tata Ultra Ex 1918.T Truck Chassis Depth
Chassis Depth 250 mm
Tata Ultra Ex 1918.T Truck Chassis Flange width
Chassis Flange width 65 mm
Tata Ultra Ex 1918.T Truck Chassis Thickness
Chassis Thickness 7 mm
