Eicher Pro 6055/1 XP tractor trailer specifications

Rate This Vehicle

From ₹ 34.20-35.50 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Eicher Pro 6055/1 XP 4x2 Tractor for this month

Eicher Pro 6055/1 XP - 6 Wheel Horse Highlights

Power

296

GVW

55000 Kg

Fuel

Diesel

Engine

7698 cc

Cylinders

Key Specifications of Eicher Pro 6055/1 XP 4x2 Tractor

Engine
Configuration

Eicher Pro 6055/1 XP 4x2 Tractor Engine
Engine
VEDX8 - 7.7L
Eicher Pro 6055/1 XP 4x2 Tractor Fuel Injection System
Fuel Injection System
Common Rail
Eicher Pro 6055/1 XP 4x2 Tractor Engine Displacement
Engine Displacement
7698 cc
Eicher Pro 6055/1 XP 4x2 Tractor Engine Cylinders
Engine Cylinders
6
Eicher Pro 6055/1 XP 4x2 Tractor Power
Power
296 HP@2200 rpm
Eicher Pro 6055/1 XP 4x2 Tractor Torque
Torque
1200 Nm@1200-1600 rpm
Eicher Pro 6055/1 XP 4x2 Tractor Clutch
Clutch
430 mm dia
With clutch booster
Eicher Pro 6055/1 XP 4x2 Tractor Transmission
Transmission
9 speed (8F+1CR+1R)
Eicher Pro 6055/1 XP 4x2 Tractor Gearbox
Gearbox
ET 140 S9
Eicher Pro 6055/1 XP 4x2 Tractor Gradeability
Gradeability
23%
Eicher Pro 6055/1 XP 4x2 Tractor Max Speed
Max Speed
80 Kmph
Eicher Pro 6055/1 XP 4x2 Tractor Emission Norms Compliance
Emission Norms Compliance
BS6 OBD2
Eicher Pro 6055/1 XP 4x2 Tractor Fuel Type
Fuel Type
Diesel
Eicher Pro 6055/1 XP 4x2 Tractor Fuel Tank Capacity
Fuel Tank Capacity
Diesel: 350 Litres
Ad Blue: 50 Litres
Eicher Pro 6055/1 XP 4x2 Tractor Electricals Battery
Electricals Battery
24V

Eicher Pro 6055/1 XP 4x2 Tractor Gross Combination Weight
Gross Combination Weight
55000 Kg
With 3 axle air suspended trailer
Eicher Pro 6055/1 XP 4x2 Tractor Cabin Type
Cabin Type
Sleeper cabin
Eicher Pro 6055/1 XP 4x2 Tractor Cabin Tilt mechanism
Cabin Tilt mechanism
Hydraulically tiltable
Eicher Pro 6055/1 XP 4x2 Tractor Chassis Frame
Chassis Frame
Domex frame
Eicher Pro 6055/1 XP 4x2 Tractor Axle Configuration
Axle Configuration
4x2
Eicher Pro 6055/1 XP 4x2 Tractor Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Eicher Pro 6055/1 XP 4x2 Tractor Rear Axle
Rear Axle
Fully floating, Single reduction
Final Drive Ratio 5.29
Eicher Pro 6055/1 XP 4x2 Tractor Front Suspension
Front Suspension
Parabolic leaf spring
With shock absorber
Eicher Pro 6055/1 XP 4x2 Tractor Rear Suspension
Rear Suspension
Semi elliptical laminated leaf springs
Eicher Pro 6055/1 XP 4x2 Tractor Tyres
Tyres
295/90R20
11R20 (Optional)
6+1 tyres
Eicher Pro 6055/1 XP 4x2 Tractor Wheelbase
Wheelbase
3200 mm (CBC)
Eicher Pro 6055/1 XP 4x2 Tractor Overall Length
Overall Length
5455 mm
Eicher Pro 6055/1 XP 4x2 Tractor Overall Width
Overall Width
2560 mm
Eicher Pro 6055/1 XP 4x2 Tractor Overall Height
Overall Height
2915 mm
Eicher Pro 6055/1 XP 4x2 Tractor Chassis Depth
Chassis Depth
285 mm
Eicher Pro 6055/1 XP 4x2 Tractor Chassis Flange width
Chassis Flange width
76 mm
Eicher Pro 6055/1 XP 4x2 Tractor Chassis Thickness
Chassis Thickness
7 mm

Eicher Pro 6055/1 XP 4x2 Tractor Specification Highlights

Lets explain the engine performance and body configuration of the Eicher Pro 6055/1 xP- 4x2 tractor trailer. The gross vehicle weight of the Eicher Pro 6055/1 xP - 4x2 tractor trailer is 55000 kilograms. This 6-chakka tractor trailer is empowered by a 6-cylinder VEDx8 - 7.7L powerful engine of 7698 cc. It produces a power of 296 horsepower and a maximum torque of 1200 Nm. This tractor-trailer is available in an axle configuration of 4x2. The power transmission of the Eicher Pro 6055/1 xP - 4x2 tractor trailer is controlled by a 9-speed gearbox system. The front and the rear suspensions are coupled with parabolic leaf springs with hydraulic shock absorbers and semi-elliptical leaf with Auxiliary springs. The wheelbase size of the Eicher Pro 6055/1 xP - 4x2 tractor trailer is 3200 mm and the Tyre size is 295/90R20 offering a 304 mm ground clearance. This tractor-trailer offers a 23% gradeability. It comes with a sleeper-type cabin. The Eicher Pro 6055/1 xP - 4x2 tractor-trailer comes under the BS6 OBD2 emission norms. Some other configurations are mentioned in the table above.
