Tata Intra V30 CX Flatbed specifications

Rate This Vehicle

From ₹ 7.77 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata Intra V30 CX Flatbed Pickup for this month

Tata Intra V30 CX Flatbed - 4 Tyre Highlights

Power

GVW

2565 Kg

Fuel

Diesel

Engine

1496 cc

Cylinders

Key Specifications of Tata Intra V30 CX Flatbed Pickup

Engine
Configuration

Tata Intra V30 CX Flatbed Pickup Engine
Engine
1.5L DI engine
Tata Intra V30 CX Flatbed Pickup Engine Displacement
Engine Displacement
1496 cc
Tata Intra V30 CX Flatbed Pickup Engine Cylinders
Engine Cylinders
4
Tata Intra V30 CX Flatbed Pickup Power
Power
70 HP
Tata Intra V30 CX Flatbed Pickup Torque
Torque
140 Nm
Tata Intra V30 CX Flatbed Pickup Clutch
Clutch
Single plate dry clutch
215 mm dia
Tata Intra V30 CX Flatbed Pickup Transmission
Transmission
5 speed (5F+1R)
Tata Intra V30 CX Flatbed Pickup Gearbox
Gearbox
Synchromesh
With cable shift
Tata Intra V30 CX Flatbed Pickup Gradeability
Gradeability
37%
Tata Intra V30 CX Flatbed Pickup Max Speed
Max Speed
80 Kmph
Tata Intra V30 CX Flatbed Pickup Emission Norms Compliance
Emission Norms Compliance
BS6
Tata Intra V30 CX Flatbed Pickup Fuel Type
Fuel Type
Diesel
Tata Intra V30 CX Flatbed Pickup Fuel Tank Capacity
Fuel Tank Capacity
35 Litres

Tata Intra V30 CX Flatbed Pickup GVW
GVW
2565 Kg
Tata Intra V30 CX Flatbed Pickup Payload
Payload
1300 Kg
Tata Intra V30 CX Flatbed Pickup Vehicle Configuration
Vehicle Configuration
Day Cabin with Flat Bed Body
Tata Intra V30 CX Flatbed Pickup Seating Capacity
Seating Capacity
D+1
Tata Intra V30 CX Flatbed Pickup Axle Configuration
Axle Configuration
4x2
Tata Intra V30 CX Flatbed Pickup Front Suspension
Front Suspension
Semi elliptical leaf spring
Tata Intra V30 CX Flatbed Pickup Rear Suspension
Rear Suspension
Semi elliptical leaf springs
Tata Intra V30 CX Flatbed Pickup Anti Roll Bar
Anti Roll Bar
Front
Tata Intra V30 CX Flatbed Pickup Tyres
Tyres
185 R14
Tata Intra V30 CX Flatbed Pickup Wheelbase
Wheelbase
2450 mm
Tata Intra V30 CX Flatbed Pickup Turning Circle Diameter
Turning Circle Diameter
10.5 m
Tata Intra V30 CX Flatbed Pickup Ground Clearance
Ground Clearance
175 mm
Tata Intra V30 CX Flatbed Pickup Overall Length
Overall Length
4460 mm
Tata Intra V30 CX Flatbed Pickup Load Body Dimensions
Load Body Dimensions
8.8 x 5.3 ft

Tata Intra V30 CX Flatbed Pickup Specification Highlights

Exploring the key specifications of the Tata Intra V30 Cx Flatbed mini truck specifications. Tata Intra V30 Cx Flatbed mini truck is equipped with a 1.5L DI engine of 1496 cc displacement. A 5-speed (5F+1R) gearbox is added to manage its power transmission. With superior mileage, the Tata Intra V30 Cx Flatbed has a fuel tank capacity of 35 liters and can travel miles without refueling. The Tata Intra V30 Cx Flatbed has a payload capacity of 1300 kilograms with a gross vehicle weight of 2565 kilograms. With a wheelbase of 2450 mm and an optimum 4460 mm overall vehicle length, the Tata Intra V30 Cx Flatbed offers a superior body size of 8.8 x 5.3 feet. This Tata small commercial vehicle comes fitted with tyres of the size 185 r14 offering a superior 175 mm ground clearance.
