BharatBenz 1217R Truck GVW
GVW 11990 Kg
BharatBenz 1217R Truck Vehicle Configuration
Vehicle Configuration Cabin and chassis
Cabin with load body
BharatBenz 1217R Truck Load Body Options
Load Body Options Fixed Side Deck
Drop Side Deck
High Side Deck
BharatBenz 1217R Truck Loading Span
Loading Span 14 ft
17 ft
20 ft
21 ft
BharatBenz 1217R Truck Cabin Type
Cabin Type Day cab
BharatBenz 1217R Truck Cabin Tilt mechanism
Cabin Tilt mechanism Manually tiltable
BharatBenz 1217R Truck Chassis Frame
Chassis Frame Ladder type with cross members
BharatBenz 1217R Truck Axle Configuration
Axle Configuration 4x2
BharatBenz 1217R Truck Front Axle
Front Axle IF 5
BharatBenz 1217R Truck Rear Axle
Rear Axle DANA S 145
BharatBenz 1217R Truck Front Suspension
Front Suspension Multileaf Spring
BharatBenz 1217R Truck Rear Suspension
Rear Suspension Multileaf Spring
BharatBenz 1217R Truck Anti Roll Bar
Anti Roll Bar Front: Standard
Rear Optional
BharatBenz 1217R Truck Tyres
Tyres 8.25R20
255/70R22.5 (Optional)
BharatBenz 1217R Truck Wheelbase
Wheelbase 3360 mm
3760 mm
4250 mm
4800 mm
5050 mm
BharatBenz 1217R Truck Turning Circle Diameter
Turning Circle Diameter 13.9 m (3360 wb)
14.8 m (3760 wb)
16.7 m (4250 wb)
18.7 m (4800 wb)
19.7 m (5050 wb)
BharatBenz 1217R Truck Ground Clearance
Ground Clearance 205 mm
BharatBenz 1217R Truck Overall Length
Overall Length 6380 mm (3360 wb)
7075 mm (3760 wb)
8030 mm (4250 wb)
8580 mm (4800 wb)
9295 mm (5050 wb)
BharatBenz 1217R Truck Overall Width
Overall Width 2420 mm
BharatBenz 1217R Truck Overall Height
Overall Height 2500 mm
BharatBenz 1217R Truck Front Overhang
Front Overhang 1275 mm
BharatBenz 1217R Truck Rear Overhang
Rear Overhang 1745 mm (3360 wb)
2040 mm (3760 wb)
2505 mm (4250 wb)
2505 mm (4800 wb)
2970 mm (5050 wb)
BharatBenz 1217R Truck Chassis Depth
Chassis Depth 228 mm
BharatBenz 1217R Truck Chassis Flange width
Chassis Flange width 80 mm
BharatBenz 1217R Truck Chassis Thickness
Chassis Thickness 6 mm
