Tata 1916 LPT truck specifications

Name: Tata 1916 LPT
Brand: Tata
SKU: TBN-20-5C5980

Rate This Vehicle

From ₹ 27.04-29.33 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata 1916 LPT Truck for this month

Tata 1916 LPT - 6 Tyre Truck Highlights

Power

160

GVW

18500 Kg

Fuel

Diesel

Engine

3300 cc

Cylinders

Key Specifications of Tata 1916 LPT Truck

Engine
Configuration

Tata 1916 LPT Truck Engine
Engine
3.3L
Tata 1916 LPT Truck Fuel Injection System
Fuel Injection System
Common Rail
Tata 1916 LPT Truck Engine Displacement
Engine Displacement
3300 cc
Tata 1916 LPT Truck Engine Cylinders
Engine Cylinders
4
Tata 1916 LPT Truck Power
Power
160 HP
Tata 1916 LPT Truck Torque
Torque
475 Nm
Tata 1916 LPT Truck Clutch
Clutch
330 mm dia
With clutch booster
Tata 1916 LPT Truck Transmission
Transmission
5 speed (5F+1R)
Tata 1916 LPT Truck Gearbox
Gearbox
GBS 550
Tata 1916 LPT Truck Gradeability
Gradeability
24%
Tata 1916 LPT Truck Max Speed
Max Speed
80 Kmph
Tata 1916 LPT Truck Emission Norms Compliance
Emission Norms Compliance
BS6 OBD2
Tata 1916 LPT Truck Fuel Type
Fuel Type
Diesel
Tata 1916 LPT Truck Fuel Tank Capacity
Fuel Tank Capacity
Diesel: 160 Litres
Diesel: 250 Litres (Optional)
Ad Blue: 25 Litres
Metal tank

Tata 1916 LPT Truck GVW
GVW
18500 Kg
Tata 1916 LPT Truck Payload
Payload
13.2 tons*
Tata 1916 LPT Truck Vehicle Configuration
Vehicle Configuration
Cabin chassis with PTO
Cabin with load body
Cowl chassis
Tata 1916 LPT Truck Load Body Options
Load Body Options
High Side Deck
Tata 1916 LPT Truck Loading Span
Loading Span
17 ft
20 ft
22 ft
24 ft
Tata 1916 LPT Truck Cabin Type
Cabin Type
Day cab
Tata 1916 LPT Truck Chassis Frame
Chassis Frame
Ladder type with cross members
Tata 1916 LPT Truck Axle Configuration
Axle Configuration
4x2
Tata 1916 LPT Truck Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata 1916 LPT Truck Rear Axle
Rear Axle
Fully Floating
Tata 1916 LPT Truck Front Suspension
Front Suspension
Parabolic leaf springs
Tata 1916 LPT Truck Rear Suspension
Rear Suspension
Semi elliptical leaf springs
Tata 1916 LPT Truck Anti Roll Bar
Anti Roll Bar
Yes
Tata 1916 LPT Truck Tyres
Tyres
295/90R20 (Tube)
6+1 tyres
Tata 1916 LPT Truck Wheelbase
Wheelbase
3920 mm
4530 mm
4920 mm
5300 mm
Tata 1916 LPT Truck Turning Circle Diameter
Turning Circle Diameter
15.9 m (3920 wb)
17.7 m (4530 wb)
19 m (4920 wb)
20.3 m (5300 wb)
Tata 1916 LPT Truck Overall Length
Overall Length
7411 mm (3920 wb)
8315 mm (4530 wb)
8950 mm (4920 wb)
9565 mm (5300 wb)

Tata 1916 LPT Truck Specification Highlights

Check all the Tata 1916 LPT specifications on TrucksBuses in the table above The main driveline of this Tata truck includes a 3300 cc 4 cylinder engine that produces a maximum power of and a torque of It gets mated to 5 speed (5F+1R), GBS 550 gearbox A gross weight of 18500 kg and multiple configurations allows the owner to carry multiple kinds of goods as per requirement There are multiple features in this Tata truck for enhancing driver comfort Other Tata 1916 LPT truck specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the tables above.
