Tata LPT 407 EX2 CNG truck specifications

Rate This Vehicle

From ₹ 15-16 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata LPT 407 EX2 CNG Truck for this month

Download Tata LPT 407 EX2 CNG Truck Brochure

Check out the Tata LPT 407 EX2 CNG Truck PDF brochure at TrucksBuses.com with all features and specifications.

Tata LPT 407 EX2 CNG - 4 Tyre Truck Highlights

Power

GVW

7250 Kg

Fuel

CNG

Engine

3783 cc

Cylinders

Key Specifications of Tata LPT 407 EX2 CNG Truck

Engine
Configuration

Tata LPT 407 EX2 CNG Truck Engine
Engine
Tata 3.8 SGI NA
Tata LPT 407 EX2 CNG Truck Fuel Injection System
Fuel Injection System
Common rail with electronic injectors
Tata LPT 407 EX2 CNG Truck Engine Displacement
Engine Displacement
3783 cc
Tata LPT 407 EX2 CNG Truck Engine Cylinders
Engine Cylinders
4
Tata LPT 407 EX2 CNG Truck Power
Power
85 HP@2500 rpm
Tata LPT 407 EX2 CNG Truck Torque
Torque
270 Nm@1200-1500 rpm
Tata LPT 407 EX2 CNG Truck Clutch
Clutch
280 mm dia
Tata LPT 407 EX2 CNG Truck Transmission
Transmission
5 speed manual (5F+1R)
Tata LPT 407 EX2 CNG Truck Gearbox
Gearbox
GBS 27, Synchromesh
Tata LPT 407 EX2 CNG Truck Gradeability
Gradeability
23%
Tata LPT 407 EX2 CNG Truck Max Speed
Max Speed
84 Kmph
Tata LPT 407 EX2 CNG Truck Emission Norms Compliance
Emission Norms Compliance
BSIV
Tata LPT 407 EX2 CNG Truck Fuel Type
Fuel Type
CNG
Tata LPT 407 EX2 CNG Truck Fuel Tank Capacity
Fuel Tank Capacity
240 Litres
Tata LPT 407 EX2 CNG Truck Electricals Battery
Electricals Battery
12V, 100 Ah
Alternator : 65 Amps

Tata LPT 407 EX2 CNG Truck GVW
GVW
7250 Kg
Tata LPT 407 EX2 CNG Truck Kerb Weight
Kerb Weight
3310 Kg (FSD)
3545 Kg (HSD)
Tata LPT 407 EX2 CNG Truck Vehicle Configuration
Vehicle Configuration
Cabin and chassis
Cabin with load body options
Tata LPT 407 EX2 CNG Truck Loading Span
Loading Span
13.8 ft (FSD)
14.33 ft (HSD)
Tata LPT 407 EX2 CNG Truck Cabin Type
Cabin Type
Day cab
Tata LPT 407 EX2 CNG Truck Cabin Tilt mechanism
Cabin Tilt mechanism
Manually tiltable
Tata LPT 407 EX2 CNG Truck Chassis Frame
Chassis Frame
Ladder type with cross members
Tata LPT 407 EX2 CNG Truck Axle Configuration
Axle Configuration
4x2
Tata LPT 407 EX2 CNG Truck Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata LPT 407 EX2 CNG Truck Rear Axle
Rear Axle
Fully Floating, Single reduction hypoid gears
Tata LPT 407 EX2 CNG Truck Front Suspension
Front Suspension
Parabolic leaf spring
With telescopic shock absorbers
Tata LPT 407 EX2 CNG Truck Rear Suspension
Rear Suspension
Semi-elliptical leaf springs
With telescopic shock absorbers
Tata LPT 407 EX2 CNG Truck Tyres
Tyres
8.25x16â€“16 PR
4+1 tyres
Tata LPT 407 EX2 CNG Truck Wheelbase
Wheelbase
3400 mm
Tata LPT 407 EX2 CNG Truck Turning Circle Diameter
Turning Circle Diameter
12.3 m
Tata LPT 407 EX2 CNG Truck Ground Clearance
Ground Clearance
219 mm
Tata LPT 407 EX2 CNG Truck Overall Length
Overall Length
5956 mm (HSD)
Tata LPT 407 EX2 CNG Truck Overall Width
Overall Width
2198 mm (HSD)
2140 mm (FSD)
Tata LPT 407 EX2 CNG Truck Overall Height
Overall Height
2350 mm
Tata LPT 407 EX2 CNG Truck Load Body Width
Load Body Width
2042 mm (FSD)
Tata LPT 407 EX2 CNG Truck Front Overhang
Front Overhang
1275 mm
Tata LPT 407 EX2 CNG Truck Rear Overhang
Rear Overhang
1000 mm

Tata LPT 407 EX2 CNG Truck Specification Highlights

Check all the Tata LPT 407 EX2 CNG specifications on TrucksBuses in the table above The main driveline of this Tata truck includes a 3783 cc 4 cylinder engine that produces a maximum power of 85 HP and a torque of 270 Nm It gets mated to 5 speed manual (5F+1R), GBS 27, Synchromesh gearbox A gross weight of 7250 kg and multiple configurations allows the owner to carry multiple kinds of goods as per requirement There are multiple features in this Tata truck for enhancing driver comfort Other Tata LPT 407 EX2 CNG truck specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the tables above.
