Tata Signa 3118.T - 6x2 BS6 truck specifications

Name: Tata Signa 3118.T - 6x2
Brand: Tata
SKU: TBN-20-F1A224

Rate This Vehicle

From ₹ 38.06 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata Signa 3118.T 6x2 Truck for this month

Download Tata Signa 3118.T 6x2 Truck Brochure

Check out the Tata Signa 3118.T 6x2 Truck PDF brochure at TrucksBuses.com with all features and specifications.

Tata Signa 3118.T - 6x2 - 12 Tyre Truck Highlights

Power

186

GVW

31000 Kg

Fuel

Diesel

Engine

5635 cc

Cylinders

Key Specifications of Tata Signa 3118.T 6x2 Truck

Engine
Configuration

Tata Signa 3118.T 6x2 Truck Engine
Engine
Cummins ISBe 5.6L
Tata Signa 3118.T 6x2 Truck Fuel Injection System
Fuel Injection System
Common Rail
Tata Signa 3118.T 6x2 Truck Engine Displacement
Engine Displacement
5635 cc
Tata Signa 3118.T 6x2 Truck Engine Cylinders
Engine Cylinders
6
Tata Signa 3118.T 6x2 Truck Power
Power
186 HP@2300 rpm
Tata Signa 3118.T 6x2 Truck Torque
Torque
850 Nm@1000-1600 rpm
Tata Signa 3118.T 6x2 Truck Clutch
Clutch
380 mm dia
Tata Signa 3118.T 6x2 Truck Transmission
Transmission
6 speed (6F+1R)
Tata Signa 3118.T 6x2 Truck Gearbox
Gearbox
G950
G750 (for 68 wheelbase)
Tata Signa 3118.T 6x2 Truck Max Speed
Max Speed
80 Kmph
Tata Signa 3118.T 6x2 Truck Emission Norms Compliance
Emission Norms Compliance
BS6
Tata Signa 3118.T 6x2 Truck Fuel Type
Fuel Type
Diesel
Tata Signa 3118.T 6x2 Truck Fuel Tank Capacity
Fuel Tank Capacity
365 Litres
Polymer tank
With anti-fuel theft

Tata Signa 3118.T 6x2 Truck GVW
GVW
31000 Kg
Tata Signa 3118.T 6x2 Truck Vehicle Configuration
Vehicle Configuration
Cabin and chassis
Cabin with load body
Tata Signa 3118.T 6x2 Truck Loading Span
Loading Span
24 ft
32 ft
Tata Signa 3118.T 6x2 Truck Cabin Type
Cabin Type
Sleeper cabin
Tata Signa 3118.T 6x2 Truck Cabin Tilt mechanism
Cabin Tilt mechanism
Hydraulically tiltable
Tata Signa 3118.T 6x2 Truck Chassis Frame
Chassis Frame
Ladder type straight frame
Tata Signa 3118.T 6x2 Truck Axle Configuration
Axle Configuration
6x2
Tata Signa 3118.T 6x2 Truck Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata Signa 3118.T 6x2 Truck Rear Axle
Rear Axle
Single reduction RA 110LD / RA 109RR (68 wb)
RAR: 4.88 / 5.12 (68 b)
Tata Signa 3118.T 6x2 Truck Front Suspension
Front Suspension
Parabolic leaf springs
Tata Signa 3118.T 6x2 Truck Rear Suspension
Rear Suspension
Semi elliptical leaf springs
Bell crank
Tata Signa 3118.T 6x2 Truck Tyres
Tyres
295/90R20 (Tube)
10+1 tyres
Tata Signa 3118.T 6x2 Truck Wheelbase
Wheelbase
5505 mm
6750 mm
Tata Signa 3118.T 6x2 Truck Overall Width
Overall Width
2440 mm
Tata Signa 3118.T 6x2 Truck Front Track
Front Track
1964 mm
Tata Signa 3118.T 6x2 Truck Rear Track
Rear Track
1817 mm
Tata Signa 3118.T 6x2 Truck Chassis Depth
Chassis Depth
285 mm
Tata Signa 3118.T 6x2 Truck Chassis Flange width
Chassis Flange width
65 mm
Tata Signa 3118.T 6x2 Truck Chassis Thickness
Chassis Thickness
8.5 mm
7 mm (68 wb)

Tata Signa 3118.T 6x2 Truck Specification Highlights

To obtain comprehensive details on the specifications of new Tata Signa 3118.T 6x2, kindly refer to the table provided by TrucksBuses above. This Tata 10 wheeler truck is equipped with a 6-cylinder engine boasting a displacment of 5635 cc, capable of generating a maximum power output of 186 HP and a torque of 850 Nm. The 10-wheeler Tata truck has variants that suit your needs, such as a cabin with chassis or cabin with load body. It has a body length of 24 feet and 32 feet, which makes it ideal for various applications. The new Tata Signa 3118.T 10 chakka truck features a sleeper cabin with hydraulically tiltable function, as well as a parabolic leaf spring in the front suspension and semi-elliptical leaf spring with bell crank in the rear suspension. For the latest specifications of the Tata 10 tyres BS6 truck such as chassis, tyre size, axle, turning circle diameter, gradeability and wheelbase check this tab.
