Ashok Leyland U3120 POL Tanker Specifications

*Ex - showroom Price of Ashok Leyland U3120 POL Tanker is 31.2 Lakh* Onwards

From ₹ 31.2 Lakh* Onwards
*Ex-showroom Price


Don't miss out on the best discount offers on Ashok Leyland U3120 POL Tanker for this month

Ashok Leyland U3120 POL - 10 Wheeler Truck Highlights

Power

Ashok Leyland U3120 POL Tanker Power

200
GVW

Ashok Leyland U3120 POL Tanker GVW

31000 Kg
Fuel

Ashok Leyland U3120 POL Tanker Fuel

Diesel
Engine

Ashok Leyland U3120 POL Tanker Engine

5660 cc
Cylinders

Ashok Leyland U3120 POL Tanker Cylinders

6

Key Specifications of Ashok Leyland U3120 POL Tanker

  • Engine
    H series CRS
    iGen-6 technology
  • Fuel Injection System
    Common Rail
  • Engine Displacement
    5660 cc
  • Engine Cylinders
    6
  • Power
    200 HP
  • Torque
    700 Nm
  • Clutch
    380 mm dia
    Organic
    With clutch booster
  • Transmission
    6 speed (6F+1R)
    With cable shift
  • Max Speed
    60 Kmph
  • Emission Norms Compliance
    BS6
  • Fuel Type
    Diesel
  • Fuel Tank Capacity
    Diesel: 375 Litres
    Ad Blue: 48 Litres
    Polymer tank
  • Electricals Battery
    24V, 120 Ah / 150 Ah (AC)
  • GVW
    31000 Kg
  • Vehicle Configuration
    Cowl with Chassis
    Cabin and chassis
  • Loading Span
    25 ft
  • Cabin Type
    Sleeper cabin
  • Cabin Tilt mechanism
    Hydraulically tiltable
  • Chassis Frame
    HSS material, bolted construction
  • Axle Configuration
    6x2
  • Front Axle
    Forged I Beam, Reverse Elliot Type
  • Rear Axle
    Fully floating, Single speed
  • Front Suspension
    Semi elliptical leaf springs
    Parabolic leaf spring (Optional)
  • Rear Suspension
    Semi elliptical leaf springs
    Slipper suspension (Optional)
  • Anti Roll Bar
    Optional in front
  • Tyres
    295/90R20 (Tube)
    10+1 tyres
  • Wheelbase
    4930 mm
  • Turning Circle Diameter
    20.2 m
  • Overall Length
    9710 mm
  • Overall Width
    2570 mm
  • Overall Height
    3247 mm
  • Front Track
    2084 mm
  • Rear Track
    1876 mm
  • Chassis Depth
    275 mm
  • Chassis Flange width
    75 mm
  • Chassis Thickness
    8 mm

Ashok Leyland U3120 POL Tanker Specification Highlights

Explaining the specific parameters of the 10-wheeler Ashok Leyland POL truck including engine performance and body configuration. The Ashok Leyland U3120 is equipped with a 5660 cc 6-cylinder engine that produces a peak power of 200 horsepower and a maximum torque of 700 Nm. This impressive power output is paired with a 6-speed and cable shift gearbox, which contributes to its excellent fuel efficiency. The maximum speed of the truck is 60 kilometers/hour. It is operated by diesel fuel and comes under BS-VI emission norms compliance. The 10-wheeler Ashok Leyland POL truck comes with a fuel tank capacity of 375 liters Ad Blue 48 liters and a polymer tank. The body configuration of the truck has a cabin and cowl with chassis. Semi-elliptical leaf springs are present at both front and rear suspensions. With a wheelbase of 4930 mm, this truck ensures stability during operation and minimizes the risk of rollover. The truck is fitted with tyres size of 295/90R20. The gross weight capacity of the truck is 31,000 kilograms, along with various configurations that enable the transportation of diverse types of cargo as needed.

Frequently Asked Questions on Ashok Leyland U3120 POL Tanker

Ashok Leyland U3120 POL price starts from Rs 31.2 Lakh* Onwards . The 2024 price of Ashok Leyland U3120 POL can vary slightly from state to state and city to city.

GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Ashok Leyland U3120 POL GVW is 31000 Kg

Ashok Leyland U3120 POL comes with 6 cylinder H series CRS# iGen-6 technology engine and the engine displacement is 5660 cc

In terms of performance, Ashok Leyland U3120 POL produces a maximum power of 200 HP and a maximum torque of 700 Nm

Ashok Leyland U3120 POL comes with a 6 speed (6F+1R)# With cable shift transmission along with a 380 mm dia# Organic# With clutch booster clutch

Ashok Leyland U3120 POL comes with Diesel fuel option and its fuel tank capacity is Diesel: 375 Litres# Ad Blue: 48 Litres# Polymer tank

Ashok Leyland U3120 POL is available in multiple body options of 9710 mm

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Ashok Leyland U3120 POL is expected to be around Rs Not Available for a 5 year period

The tyre size of Ashok Leyland U3120 POL is 295/90R20 (Tube)# 10+1 tyres

Ashok Leyland U3120 POL comes with Air brakes# With ASA

Ashok Leyland U3120 POL truck comes with a standard warranty of 4 Years / 4 Lakh Km
