Tata Ultra 1923.T truck specifications

Name: Tata Ultra 1923.T
Brand: Tata
SKU: TBN-20-8D34BE

Rate This Vehicle

From ₹ 26.99-27.80 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers on Tata Ultra 1923.T Truck for this month

Tata Ultra 1923.T - 6 Tyre Truck Highlights

Power

230

GVW

18500 Kg

Fuel

Diesel

Engine

5635 cc

Cylinders

Key Specifications of Tata Ultra 1923.T Truck

Engine
Configuration

Tata Ultra 1923.T Truck Engine
Engine
Cummins 5.6L
Tata Ultra 1923.T Truck Fuel Injection System
Fuel Injection System
Common Rail
Tata Ultra 1923.T Truck Engine Displacement
Engine Displacement
5635 cc
Tata Ultra 1923.T Truck Engine Cylinders
Engine Cylinders
6
Tata Ultra 1923.T Truck Power
Power
230 HP
Tata Ultra 1923.T Truck Torque
Torque
850 Nm
Tata Ultra 1923.T Truck Transmission
Transmission
6 speed (6F+1R)
Dashboard mounted gear lever
Tata Ultra 1923.T Truck Gearbox
Gearbox
Synchromesh
Tata Ultra 1923.T Truck Max Speed
Max Speed
80 Kmph
Tata Ultra 1923.T Truck Emission Norms Compliance
Emission Norms Compliance
BS6 OBD2
Tata Ultra 1923.T Truck Fuel Type
Fuel Type
Diesel
Tata Ultra 1923.T Truck Fuel Tank Capacity
Fuel Tank Capacity
365 Litres
365+365 Litres (32 ft)
Polymer tank
With anti-fuel theft

Tata Ultra 1923.T Truck GVW
GVW
18500 Kg
Tata Ultra 1923.T Truck Payload
Payload
11-12 Tons*
Tata Ultra 1923.T Truck Vehicle Configuration
Vehicle Configuration
Cabin and chassis
Cabin with load body
Tata Ultra 1923.T Truck Load Body Options
Load Body Options
Fixed Side Deck
High Side Deck
Container
Tata Ultra 1923.T Truck Loading Span
Loading Span
18 ft
20 ft
24 ft
32 ft
Tata Ultra 1923.T Truck Cabin Type
Cabin Type
Sleeper cabin
Tata Ultra 1923.T Truck Cabin Tilt mechanism
Cabin Tilt mechanism
Hydraulically tiltable
Tata Ultra 1923.T Truck Chassis Frame
Chassis Frame
Ladder type straight frame
Tata Ultra 1923.T Truck Axle Configuration
Axle Configuration
4x2
Tata Ultra 1923.T Truck Front Axle
Front Axle
Forged I Beam, Reverse Elliot Type
Tata Ultra 1923.T Truck Rear Axle
Rear Axle
Single reduction
Tata Ultra 1923.T Truck Front Suspension
Front Suspension
Parabolic leaf springs
Tata Ultra 1923.T Truck Rear Suspension
Rear Suspension
Semi elliptical leaf springs
Tata Ultra 1923.T Truck Tyres
Tyres
295/90R20 (Tube)
6+1 tyres
Tata Ultra 1923.T Truck Wheelbase
Wheelbase
4225 mm
4855 mm
5195 mm
6750 mm
Tata Ultra 1923.T Truck Overall Length
Overall Length
7380 mm (4225 wb)
9495 mm (5195 mm)
Tata Ultra 1923.T Truck Chassis Depth
Chassis Depth
250 mm
Tata Ultra 1923.T Truck Chassis Flange width
Chassis Flange width
65 mm

Tata Ultra 1923.T Truck Specification Highlights

Check all the Tata Ultra 1923.T specifications on TrucksBuses in the table above The main driveline of this Tata truck includes a 5635 cc 6 cylinder engine that produces a maximum power of and a torque of It gets mated to 6 speed (6F+1R), Dashboard mounted gear lever, Synchromesh gearbox A gross weight of 18500 kg and multiple configurations allows the owner to carry multiple kinds of goods as per requirement There are multiple features in this Tata truck for enhancing driver comfort Other Tata Ultra 1923.T truck specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the tables above.
