Tata Signa 2823.K 9S Bogie Tipper Specifications

*Ex - showroom Price of Tata Signa 2823.K 9S Bogie Tipper is 37.4-41.72 Lakh*

From ₹ 37.4-41.72 Lakh*
*Ex-showroom Price


Don't miss out on the best discount offers on Tata Signa 2823.K 9S Bogie Tipper for this month

Tata Signa 2823.K 9S Bogie - 10 Tyre Tipper Highlights

Power

Tata Signa 2823.K 9S Bogie Tipper Power

220
GVW

Tata Signa 2823.K 9S Bogie Tipper GVW

28000 Kg
Fuel

Tata Signa 2823.K 9S Bogie Tipper Fuel

Diesel
Engine

Tata Signa 2823.K 9S Bogie Tipper Engine

5635 cc
Cylinders

Tata Signa 2823.K 9S Bogie Tipper Cylinders

6

Key Specifications of Tata Signa 2823.K 9S Bogie Tipper

  • Engine
    Cummins ISBe 5.6L
  • Fuel Injection System
    Common Rail
  • Engine Displacement
    5635 cc
  • Engine Cylinders
    6
  • Power
    220 HP@2300 rpm
  • Torque
    850 Nm@1000-1600 rpm
  • Clutch
    380 mm dia
    Organic
  • Transmission
    9 speed (9F+1R)
  • Gearbox
    G1150
  • Emission Norms Compliance
    BS6
  • Fuel Type
    Diesel
  • Fuel Tank Capacity
    300 Litres
    Polymer tank
    With anti-fuel theft
  • GVW
    28000 Kg
  • Vehicle Configuration
    Cabin with Box body
  • Load Body Options
    16 Cu.M Box body
  • Cabin Type
    Day Cab
  • Cabin Tilt mechanism
    Hydraulically tiltable
  • Chassis Frame
    Ladder type straight frame
  • Axle Configuration
    6x4
  • Front Axle
    Forged I Beam, Reverse Elliot Type
  • Rear Axle
    Single reduction, Hypoid gears, Fully Floating Axle
    RA 109 S
  • Front Suspension
    Semi elliptical leaf springs
  • Rear Suspension
    Bogie suspension
  • Anti Roll Bar
    Yes
  • Tyres
    295/95 D20
    10+1 tyres
  • Wheelbase
    3880 mm
  • Chassis Thickness
    7 mm
    With 7 mm reinforcement

Tata Signa 2823.K 9S Bogie Tipper Specification Highlights

Let us see this section about the configuration of the body and engine performance. Here we understand the key specifications of the Tata Signa 2823.K 9S Bogie. This 10-wheeler dumper of the Signa series uses a Cummins ISBe 5.6L engine with a displacement of 5635 cc that exerts a high-end torque of 850 Nm and a power of 220 horsepower. The power is regulated by a 9-speed and G1150 gearbox system. It is operated by diesel fuel and the fuel tank capacity is approximately 300 liter. The vehicle configuration has a cabin and chassis where the cabin happens with a box body and ladder-type straight chassis frame. It is available at an axle configuration of 6x4. The front and rear suspensions have semi-elliptical leaf springs and bogie suspension respectively. The size of tyres and wheelbase is 295/95 D20, and 3880mm respectively.

Frequently Asked Questions on Tata Signa 2823.K 9S Bogie Tipper

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Tata Signa 2823.K 9S Bogie is expected to be around Rs 7946 for a 5 year period

Tata Signa 2823.K 9S Bogie price starts from Rs 37.4-41.72 Lakh*. The 2024 price of Tata Signa 2823.K 9S Bogie can vary slightly from state to state and city to city.

GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Tata Signa 2823.K 9S Bogie GVW is 28000 Kg

In terms of performance, Tata Signa 2823.K 9S Bogie produces a maximum power of 220 HP@2300 rpm and a maximum torque of 850 Nm@1000-1600 rpm

Tata Signa 2823.K 9S Bogie comes with a 9 speed (9F+1R) transmission along with a 380 mm dia# Organic clutch

Tata Signa 2823.K 9S Bogie comes with Diesel fuel option and its fuel tank capacity is 300 Litres# Polymer tank# With anti-fuel theft

Tata Signa 2823.K 9S Bogie is available in 16 Cu.M Box body body

The tyre size of Tata Signa 2823.K 9S Bogie is 295/95 D20# 10+1 tyres

Tata Signa 2823.K 9S Bogie comes with Air brakes

Tata Signa 2823.K 9S Bogie tipper comes with a standard warranty of 6 Years / 6000 Hrs on driveline
